Exploded view — Valves

Products

1 Valve (IN) AP0253615 No longer available

• AP0253615 Valve (IN)
  No longer available

2 Valve (IN) Available AP0253610

•

  Inlet valve Ø 30,00 mm Piaggio Group · AP0253610 · Quantity needed: 2 Available

  € 132,08

  Add to cart

3 Valve (EX) AP0253620 No longer available

• AP0253620 Valve (EX) Quantity needed: 2
  No longer available

4 Plate AP0253630 No longer available

• AP0253630 Plate Quantity needed: 2
  No longer available

5 Thrust washer 11,2/28/1 AP0227982 No longer available

• AP0227982 Thrust washer 11,2/28/1 Quantity needed: 3
  No longer available

6 Valve stem seal AP0230510 No longer available

• AP0230510 Valve stem seal Quantity needed: 5
  No longer available

7 Ext. valve spring (EX) AP0239150 No longer available

• AP0239150 Ext. valve spring (EX) Quantity needed: 5
  No longer available

8 Int. valve spring (IN) AP0838140 No longer available

• AP0838140 Int. valve spring (IN) Quantity needed: 2
  No longer available

9 Valve spring plate AP0253571 No longer available

• AP0253571 Valve spring plate Quantity needed: 5
  No longer available

10 Valve half-cone Available AP0253640

•

  Valve Half Cone Piaggio Group · AP0253640 · Quantity needed: 10 Available

  € 16,36

  Add to cart

11 Valve lifter bucket AP0253540 No longer available

• AP0253540 Valve lifter bucket Quantity needed: 4
  No longer available

12 Hex screw Available AP0841690

•

  Hexagon Screw Piaggio Group · AP0841690 · Quantity needed: 2 Available

  € 7,11

  Add to cart

13 Camshaft (Intake) AP0237095 No longer available

• AP0237095 Camshaft (Intake)
  No longer available

14 Camshaft (Exhaust) AP0237105 No longer available

• AP0237105 Camshaft (Exhaust)
  No longer available

15 Spring 2R000273 No longer available

• 2R000273 Spring
  No longer available

16 Counterweight AP0231020 No longer available

• AP0231020 Counterweight
  No longer available

17 Pin 5x23,8 Backorder AP0232910

•

  Pin 5x23,8 mm Piaggio Group · AP0232910 Backorder

  € 13,39

  Add to cart

18 Rocker arm assy., inlet AP0253605 No longer available

• AP0253605 Rocker arm assy., inlet
  No longer available

19 Screw AP0240205 No longer available

• AP0240205 Screw
  No longer available

20 Nut AP0242591 No longer available

• AP0242591 Nut
  No longer available

21 Rocker arm rod Available AP0253530

•

  Rocker Arm Push Rod Piaggio Group · AP0253530 Available

  € 32,14

  Add to cart

22 Washer AP0227451 No longer available

• AP0227451 Washer
  No longer available

23 Spring washer 12,5x21,5x0,5 AP0227455 No longer available

• AP0227455 Spring washer 12,5x21,5x0,5
  No longer available

24 Intake timing system gear AP0253945 No longer available

• AP0253945 Intake timing system gear
  No longer available

25 Exhaust timing system gear Z=36 AP0253947 No longer available

• AP0253947 Exhaust timing system gear Z=36
  No longer available

26 Spring washer AP0445441 No longer available

• AP0445441 Spring washer Quantity needed: 2
  No longer available
