Exploded view — Front Fork Iii

‹ Back to model
Aprilia RS 50 2T 1998 Aprilia RS 50 2T 1998
Front Fork Iii

Products

1 Front fork AP8203576 No longer available
  • AP8203576 Front fork
    No longer available
2 LH sleeve AP8203846 No longer available
  • AP8203846 LH sleeve
    • Fork with letter S on hub
    No longer available
  • AP8203583 LH sleeve
    • Fork without letter S on hub
    No longer available
3 RH sleeve AP8203845 No longer available
  • AP8203845 RH sleeve
    • Fork with letter S on hub
    No longer available
  • AP8203582 RH sleeve
    • Fork without letter S on hub
    No longer available
4 Fork dust seal (S) AP8203789 No longer available
  • AP8203789 Fork dust seal (S) Quantity needed: 2
    • Fork with letter S on hub
    No longer available
  • AP8203564 Fork dust seal (M) Quantity needed: 2
    • Fork with letter M on hub
    • Fork without letter S on hub
    No longer available
5 Circlip AP8203863 No longer available
  • AP8203863 Circlip Quantity needed: 2
    • Fork with letter M on hub
    • Fork without letter S on hub
    No longer available
    • Fork with letter S on hub
    Locking Ring Piaggio Group · AP8203790 · Quantity needed: 2 Available · Shipped in 3–5 working days
    € 5,47
6 Fork oil seal AP8203698 No longer available
  • AP8203698 Fork oil seal Quantity needed: 2
    • Fork with letter S on hub
    No longer available

    Alternatives from other brands

    FORK OIL SEAL KIT Ariete · ARI080 Available · Shipped in 4–7 working days
    € 19,05
  • AP8203565 Fork oil seal (M) Quantity needed: 2
    • Fork with letter M on hub
    • Fork without letter S on hub
    Fork Seal Marzocchi, 30x40x8 mm Piaggio Group · ap8203565 Available · Shipped in 3–5 working days
    € 17,99
    Fork Seal Marzocchi, 30x40x8 mm Piaggio Group · ap8203565 Available · Shipped in 3–5 working days
    € 17,99
    Fork Seal Marzocchi, 30x40x8 mm Piaggio Group · AP8203565 Available · Shipped in 3–5 working days
    € 17,99

    Alternatives from other brands

    Front Fork Seal Set 30x40x8/9 Athena · P40FORK455011 Available · Shipped in 4–7 working days
    € 8,87
    FORK OIL SEAL KIT Ariete · ARI079 Available · Shipped in 4–7 working days
    € 17,65
7 Gasket AP8123436 No longer available
  • AP8123436 Gasket
    • Fork without letter S on hub
    No longer available
    • Fork with letter S on hub
    • Marzocchi
    • Showa
    Washer Piaggio Group · 856046 Available · Shipped in 3–5 working days
    € 2,40
8 Screw Backorder AP8203590
    • Fork without letter S on hub
    Screw M8x35 Piaggio Group · AP8203590 Backorder · Shipped in 2–4 weeks
    € 3,99
    • Fork with letter S on hub
    Screw Piaggio Group · AP8203795 Backorder · Shipped in 2–4 weeks
    € 2,73
9 Screw (M8x35) AP8203847 No longer available
  • AP8203847 Screw (M8x35)
    • Fork with letter S on hub
    No longer available
