Exploded view — Front Body - Front Mudguard

Products

1 Front mudguard AP8126946 No longer available

• AP8126946 Front mudguard
  No longer available
• AP8126933 Front mudguard
  No longer available
• AP8158856 Front mudguard, grey
  No longer available
• AP8126932 Front mudguard (Red)
  No longer available
• AP8126923 Front mudguard
  No longer available
• AP8156073 Front mudguard
  No longer available
• AP8158857 Front mudguard, grey
  No longer available
• AP8126956 Front mudguard
  No longer available
• AP8126955 Front mudguard (Red)
  No longer available
• AP8156074 Front mudguard
  No longer available

2 Front fairing lower lockup Backorder AP8148551

•

  Lock Piaggio Group · AP8148551 Backorder

  € 49,72

  Add to cart

3 Pillar Backorder AP8148024

•

  Fairing Piaggio Group · AP8148024 Backorder

  € 68,12

  Add to cart

4 Spoiler heat protection Backorder AP8117129

•

  Cover Piaggio Group · AP8117129 Backorder

  € 50,17

  Add to cart

5 Screw Available 2B014101

•

  Screw Piaggio Group · 2B014101 · Quantity needed: 4 Available

  € 3,78

  Add to cart

6 Screw (6x12) Available AP8152277

•

  Flanged Screw M6x12 Piaggio Group · AP8152277 · Quantity needed: 2 Available

  € 2,18

  Add to cart

7 Screw Available 598839

•

  Flanged Screw M6x16 Piaggio Group · 598839 · Quantity needed: 4 Available

  € 1,48

  Add to cart

8 Reflector, amber Available AP8124719

•

  Reflector yellow Piaggio Group · AP8124719 · Quantity needed: 2 Available

  € 17,01

  Add to cart

9 Nut Available AP8150204

•

  Standard nut M4 Piaggio Group · AP8150204 · Quantity needed: 4 Available

  € 2,18

  Add to cart

10 Washer (4,3x9x0,8) Available AP8150158

•

  Shim 4,3x9x0,8 mm Piaggio Group · AP8150158 · Quantity needed: 4 Available

  € 1,48

  Add to cart
