Exploded view — Frame » Front Body I - Headlight Support

‹ Back to model

Aprilia Scarabeo 50 2T 2012

Aprilia Scarabeo 50 2T 2012

Frame » Front Body I - Headlight Support

Products

1 Headlight support, black Backorder 63598100XN5

63598100XN5 Headlight support, black
- Colour: Black Aprilia (s.t.677000)
- Year of manufacture: 2012
Handlebar fairing front, black, Suffix: XN5_black Piaggio Group · 63598160XN5 ↻ Replaces 63598100XN5, which the manufacturer no longer supplies. Backorder · Shipped in 2–4 weeks

€ 159,67
63598100XR6 Headlight support, red
- Colour: Tango-Crew Red (s.t.677000)
No longer available
63598100XV2 Headlight support, green
- Colour: Carioca Green (s.t.677000)
No longer available
- Colour: Blue Click 2012 (t.s. 677049)
- Year of manufacture: 2012
Handlebar Fairing, front, blue, Suffix: XA5_light blue click Piaggio Group · 63598100XA5 Backorder · Shipped in 2–4 weeks

€ 159,67
63598100XB1 Headlight support, white
- Year of manufacture: 2010-2011
- Year of manufacture: 2012
Handlebar fairing front, white, Suffix: XB1_cult white Piaggio Group · 63598160XB1 ↻ Replaces 63598100XB1, which the manufacturer no longer supplies. Backorder · Shipped in 2–4 weeks

€ 159,67
63598100XP3 Pink headlamp panel
- Colour: Pink c (s.t.677000)
- Year of manufacture: 2012
No longer available
63598100XN6 Headlight support, black
- Colour: "Black Special ""yourz"" (t.s.677034)"
No longer available
63598100XB8 Headlight support, l.brown
- Colour: Beige Stick 2012 (t.s. 677049)
- Year of manufacture: 2012
No longer available

2 Dashboard panel, black Backorder 85175900XN5

- Colour: Black Aprilia (s.t.677000)
- Year of manufacture: 2012
Handlebar Fairing, rear, black, Suffix: XN5_black Piaggio Group · 85175900XN5 Backorder · Shipped in 2–4 weeks

€ 154,67
- Colour: Tango-Crew Red (s.t.677000)
Handlebar Fairing, rear, red, Suffix: XR6_red tango crew Piaggio Group · 85175900XR6 Backorder · Shipped in 2–4 weeks

€ 154,67
85175900XP3 Pink dashboard pane
- Colour: Pink c (s.t.677000)
- Year of manufacture: 2012
No longer available
- Year of manufacture: 2010-2011
- Year of manufacture: 2012
Handlebar Fairing, rear, white, Suffix: XB1_cult white Piaggio Group · 85175900XB1 Available · Shipped in 3–5 working days

€ 145,24
85175900XV2 Dashboard panel, green
- Colour: Carioca Green (s.t.677000)
No longer available
85175900XN6 Dashboard panel, black
- Colour: "Black Special ""yourz"" (t.s.677034)"
No longer available
- Colour: Blue Click 2012 (t.s. 677049)
- Year of manufacture: 2012
Handlebar Fairing, rear, blue, Suffix: XA5_light blue click Piaggio Group · 85175900XA5 Backorder · Shipped in 2–4 weeks

€ 154,67
85175900XB8 Beige painted dashboard
- Colour: Beige Stick 2012 (t.s. 677049)
- Year of manufacture: 2012
No longer available

3 Black plug d14 AP8268604 No longer available

AP8268604 Black plug d14 Quantity needed: 3
No longer available

4 Screw Available AP8150421

- Colour: Alitalia (t.s.899864)
- Colour: Replica Alitalia (t.s.899863)
- Colour: Replica MY13
- Colour: Replica SBK MY12
- Country: Canada
- Country: Italy
- Country: United States of America
Thread Screw 2,9x12 mm, stainless steel Piaggio Group · AP8150421 · Quantity needed: 4 Available · Shipped in 3–5 working days

€ 2,18
