Exploded view — Frame » Front Body Vi - Front Mudguard

Products

1 Front mudguard AP8156269 No longer available

• AP8156269 Front mudguard
  No longer available
• AP8156270 Front mudguard (PINK)
  No longer available
• AP8226824 Front mudguard (BLACK)
  No longer available
• AP8226845 Front mudguard, grey
  No longer available
•

  Mudguard front, blue, Manufacturer colour: blue main Piaggio Group · AP8226823 Backorder

  € 181,45

  Add to cart
• AP8226846 Front mudguard
  No longer available

2 Screw Available 2B014101

•

  Screw Piaggio Group · 2B014101 Available

  € 3,78

  Add to cart

3 Reflector, orange Available AP8224163

• AP8224163 Reflector, orange Quantity needed: 2


  Reflector for plugging in, round, yellow Piaggio Group · Ap8224163 Available

  € 12,08

  Add to cart


  Reflector for plugging in, round, yellow Piaggio Group · Ap8224163 Available

  € 12,08

  Add to cart


  Reflector for plugging in, round, yellow Piaggio Group · AP8224163 Available

  € 12,08

  Add to cart

4 Nut AP8152306 No longer available

• AP8152306 Nut Quantity needed: 2
  No longer available

5 Washer Available AP8150177

•

  Shim Piaggio Group · AP8150177 · Quantity needed: 4 Available

  € 0,99

  Add to cart

6 Screw Available AP8150444

•

  Thread Screw 4x9 mm, stainless steel Piaggio Group · AP8150444 · Quantity needed: 4 Available

  € 1,48

  Add to cart

7 Screw Available AP8152298

•

  Flanged Screw M5x16 Piaggio Group · AP8152298 Available

  € 3,80

  Add to cart

8 Washer Available AP8150382

•

  Shim 15x5,5x1,2 mm Piaggio Group · AP8150382 Available

  € 2,18

  Add to cart

9 Spacer Available 179574

•

  Spacer Piaggio Group · 179574 Available

  € 1,48

  Add to cart
