Exploded view — Front Body - Front Mudguard

Products

1 Front mudguard (Red) AP8156304 No longer available

• AP8156304 Front mudguard (Red)
  No longer available
• AP8226636 Front mudguard, reef blue
  No longer available
• AP8226874 Front mudguard, lemon yellow
  No longer available
• AP8226853 Front mudguard
  No longer available
• AP8226483 Front mudguard, blade grey
  No longer available
• AP8226482 Front mudguard, solid azure
  No longer available
• AP8226428 Front mudguard
  No longer available
• AP8226831 Front mudguard
  No longer available
• AP8226707 Front mudguard, hot red
  No longer available
•

  Mudguard blue, Manufacturer colour: blue dream Piaggio Group · AP8226875 Backorder

  € 89,06

  Add to cart
• AP8226786 Front mudguard
  No longer available
• AP8226551 Front mudguard, chr. yellow
  No longer available
• AP8226709 Front mudguard, grey
  No longer available

2 Lower shield cover Backorder AP8239281

•

  Wheel Arch Piaggio Group · AP8239281 Backorder

  € 39,93

  Add to cart

3 Brake caliper access door AP8239739 No longer available

• AP8239739 Brake caliper access door
  No longer available

4 Plug, purple AP8220519 No longer available

• AP8220519 Plug, purple
  No longer available
•

  Lock Piaggio Group · AP8248897 Available

  € 6,75

  Add to cart

5 Rubber water cooler supp. AP8220456 No longer available

• AP8220456 Rubber water cooler supp. Quantity needed: 2
  No longer available

6 Screw Available AP8150413

•

  Thread Screw 3,9x14 mm, stainless steel Piaggio Group · AP8150413 · Quantity needed: 5 Available

  € 1,69

  Add to cart

7 Nut AP8152306 No longer available

• AP8152306 Nut Quantity needed: 4
  No longer available

8 Screw Available AP8152274

•

  Flanged Screw M5x20 Piaggio Group · AP8152274 · Quantity needed: 4 Available

  € 2,18

  Add to cart
