Exploded view — Front Body - Front Fairing

‹ Back to model

Aprilia SR 125-150 2000

Products

1 Front fairing, ap.black AP8268408 No longer available

AP8268408 Front fairing, ap.black
No longer available
AP8148573 Front fairing, night blue
No longer available
AP8139711 Front fairing, a.silver
No longer available
AP8148571 Front fairing, a.silver
No longer available
AP8148502 Front fairing, fumi blue
No longer available
AP8148398 Front fairing, night blue
No longer available
AP8148575 Front fairing, fl.green
No longer available
AP8258301 Front fairing, grey
No longer available
AP8148409 Front fairing, fl.green
No longer available
AP8149906 Front fairing, black
No longer available
AP8148579 Front fairing, fumi blue
No longer available
AP8149907 Front fairing, black
No longer available

2 Upper shield guard, red AP8149910 No longer available

AP8149910 Upper shield guard, red
No longer available
AP8248655 Upper shield guard, black
No longer available
AP8148382 Upper shield guard, grey
No longer available

3 Screw Available AP8150426

Oval Head Screw 5,5x15,9 mm Piaggio Group · AP8150426 · Quantity needed: 4 Available

€ 1,48
