Exploded view — Controls I

Products

1 Rear brake lever complete AP8218236 No longer available

• AP8218236 Rear brake lever complete
  No longer available
• AP8218136 LH rear brake control
  No longer available

2 Brake lever Backorder AP8218274

•

  Brake Lever left Piaggio Group · AP8218274 Backorder

  € 39,24

  Add to cart
• AP8218153 Brake lever
  No longer available

3 Screw AP8118472 No longer available

• AP8118472 Screw
  No longer available

4 Brake lever pin AP8218114 No longer available

• AP8218114 Brake lever pin
  No longer available

5 Brake lever U-bolt AP8218154 No longer available

• AP8218154 Brake lever U-bolt
  No longer available

6 Grip AP8218275 No longer available

• AP8218275 Grip
  No longer available

7 Lever starter Available AP8212529

•

  Starter Lever Piaggio Group · AP8212529 Available

  € 15,40

  Add to cart

8 Indicator Switch Available AP8212767

•

  Indicator switch Piaggio Group · AP8212767 Available

  € 40,47

  Add to cart

9 Horn button Available AP8124209

•

  Horn button Piaggio Group · AP8124209 Available

  € 26,31

  Add to cart

10 Choke cable AP8214159 No longer available

• AP8214159 Choke cable
  No longer available

11 Nut Available AP8152300

•

  Standard nut M8 Piaggio Group · AP8152300 Available

  € 2,35

  Add to cart

12 Screw Available AP8150086

•

  Screw M10x55 Piaggio Group · AP8150086 Available

  € 3,93

  Add to cart

13 Washer Available AP8150020

•

  Shim 10,5x21x2 mm Piaggio Group · AP8150020 Available

  € 2,18

  Add to cart

14 Nut Available AP8152301

•

  Standard nut Piaggio Group · AP8152301 Available

  € 2,35

  Add to cart

15 Screw Available AP8152290

•

  Flanged Screw M8x40 Piaggio Group · AP8152290 Available

  € 2,93

  Add to cart

16 Screw Available AP8150473

•

  Oval Head Screw Piaggio Group · AP8150473 Available

  € 0,99

  Add to cart
