Exploded view — Injection Unit (ditech)

‹ Back to model
Aprilia SR 50 Di-Tech 2004 Aprilia SR 50 Di-Tech 2004
Injection Unit (ditech)

Products

1 Inlet valve (Franco Morini) Available AP3AEA000547
    • "DITECH" engine with direct fuel injection
    • Full power version
    • Version 25 kW
    Injection Piaggio Group · AP3AEA000547 Available · Shipped in 3–5 working days
    € 372,08
2 Screw AP2AVN000256 No longer available
  • AP2AVN000256 Screw Quantity needed: 2
    • "DITECH" engine with direct fuel injection
    No longer available
3 Air injector 829480 No longer available
  • 829480 Air injector
    No longer available
4 Lockup rubber AP3AVN000245 No longer available
  • AP3AVN000245 Lockup rubber
    • "DITECH" engine with direct fuel injection
    • Full power version
    • Version 25 kW
    No longer available
5 O-Ring Available AP2EAN000258
    • "DITECH" engine with direct fuel injection
    • Full power version
    • Version 25 kW
    O-Ring 21x3,5 mm Piaggio Group · AP2EAN000258 Available · Shipped in 3–5 working days
    € 12,38
6 O-Ring Available 830433
    • Injection version (C361M)
    O-Ring 18x2,5 mm Piaggio Group · 830433 Available · Shipped in 3–5 working days
    € 1,29
7 Clamp Available AP2FDN000200
    • "DITECH" engine with direct fuel injection
    Clamp Piaggio Group · AP2FDN000200 · Quantity needed: 3 Available · Shipped in 3–5 working days
    € 4,45
8 O-ring kit AP5RZR000232 No longer available
  • AP5RZR000232 O-ring kit
    • "DITECH" engine with direct fuel injection
    No longer available
9 High pressure pipe CM223702 No longer available
  • CM223702 High pressure pipe
    • Injection version (C361M)
    No longer available
10 High pressure pipe cpl. AP5RAR000102 No longer available
  • AP5RAR000102 High pressure pipe cpl.
    • "DITECH" engine with direct fuel injection
    No longer available
11 O-Ring (Upper) Available AP5RAR000109
    • "DITECH" engine with direct fuel injection
    O-Ring Ø 14,00 mm Piaggio Group · AP5RAR000109 Available · Shipped in 3–5 working days
    € 14,60
12 O-Ring (Lower) Available AP5RAR000108
    • "DITECH" engine with direct fuel injection
    O-Ring Piaggio Group · AP5RAR000108 Available · Shipped in 3–5 working days
    € 13,15
13 Gasket ring Available 834176
    • Injection version (C361M)
    Oil seal Piaggio Group · 834176 Available · Shipped in 3–5 working days
    € 10,81
14 Insulated pipe AP8220711 No longer available
  • AP8220711 Insulated pipe
    No longer available
15 Emulsion bleed valve kit AP8276090 No longer available
  • AP8276090 Emulsion bleed valve kit
    No longer available
