Exploded view — Front Fork I

Products

1 Stem base Available AP8223004

•

  Fork yoke Piaggio Group · AP8223004 Available

  € 282,01

  Add to cart

2 Plug AP8203777 No longer available

• AP8203777 Plug Quantity needed: 2
  No longer available
•

  Screw Plug Piaggio Group · AP8203561 · Quantity needed: 2 Available

  € 17,61

  Add to cart
•

  Screw Plug Piaggio Group · AP8223038 · Quantity needed: 2 Available

  € 5,55

  Add to cart

3 Seeger AP8203652 No longer available

• AP8203652 Seeger Quantity needed: 2
  No longer available
•

  Snap-in Ring Piaggio Group · AP8203778 · Quantity needed: 2 Available

  € 2,63

  Add to cart
•

  Snap-in Ring Piaggio Group · AP8223039 · Quantity needed: 2 Available

  € 2,63

  Add to cart

4 Seeger Backorder AP8203752

•

  Locking Ring Piaggio Group · AP8203752 · Quantity needed: 2 Backorder

  € 5,25

  Add to cart
• AP8203702 Seeger Quantity needed: 2
  No longer available

5 Cover AP8203779 No longer available

• AP8203779 Cover Quantity needed: 2
  No longer available
• AP8203753 Cover Quantity needed: 2
  No longer available
•

  Lid Piaggio Group · AP8223041 · Quantity needed: 2 Available

  € 6,26

  Add to cart

6 O-Ring (M) AP8203754 No longer available

• AP8203754 O-Ring (M) Quantity needed: 2
  No longer available
• AP8203780 O-Ring Quantity needed: 2
  No longer available
•

  O-Ring Piaggio Group · AP8223042 · Quantity needed: 2 Available

  € 1,45

  Add to cart

7 Pipe Available AP8203755

•

  Sleeve Piaggio Group · AP8203755 · Quantity needed: 2 Available

  € 11,02

  Add to cart

8 Spring (Small) Backorder AP8223049

•

  Return Spring Piaggio Group · AP8223049 · Quantity needed: 2 Backorder

  € 10,87

  Add to cart
• AP8203756 Spring (M) Quantity needed: 2
  No longer available
• AP8203781 Spring (S) Quantity needed: 2
  No longer available

9 Shock absorber, LH Backorder AP8203782

•

  Shock absorber left Piaggio Group · AP8203782 Backorder

  € 45,96

  Add to cart
• AP8203757 Shock absorber, LH
  No longer available

10 Fork pump ring Available AP8223046

•

  Buffer Piaggio Group · AP8223046 Available

  € 5,07

  Add to cart
• AP8203783 Fork pump ring
  No longer available
•

  Ring Piaggio Group · AP8203758 Available

  € 12,31

  Add to cart

11 Shock absorber, RH Backorder AP8203784

•

  Shock absorber right Piaggio Group · AP8203784 Backorder

  € 8,47

  Add to cart
•

  Shock absorber right Piaggio Group · AP8203759 Available

  € 16,94

  Add to cart

12 Screw Backorder AP8203762

•

  Screw M10x35 Piaggio Group · AP8203762 · Quantity needed: 2 Backorder

  € 11,07

  Add to cart

13 Return spring (Small) Backorder AP8203786

•

  Return Spring Piaggio Group · AP8203786 · Quantity needed: 2 Backorder

  € 4,20

  Add to cart
•

  Return Spring Piaggio Group · AP8223050 · Quantity needed: 2 Backorder

  € 5,34

  Add to cart
•

  Return Spring Piaggio Group · AP8123708 · Quantity needed: 2 Backorder

  € 15,73

  Add to cart

14 Front fork Backorder 85186R

•

  Fork Piaggio Group · 85186R Backorder

  € 333,65

  Add to cart

15 Plunger, complete Backorder AP8223045

•

  Shock absorber Piaggio Group · AP8223045 · Quantity needed: 2 Backorder

  € 68,26

  Add to cart
