Exploded view — Front Wheel

Products

1 R-CTO.RUEDA DLNT.C/DISCO DRD PRO R 07 8675480001 No longer available

• 8675480001 R-CTO.RUEDA DLNT.C/DISCO DRD PRO R 07
  No longer available
• 866794 R-CTO.RDA DT.C/DIS SR DRD PRO
  No longer available

2 Front wheel spindle Front Available 00H01206271

•

  Wheel Axle Piaggio Group · 00H01206271 Available

  € 26,50

  Add to cart

3 Washer Available 00032015000

•

  Shim Piaggio Group · 00032015000 Available

  € 2,77

  Add to cart

4 Nut Available 00H00300672

•

  Standard nut right hand thread Piaggio Group · 00H00300672 Available

  € 1,26

  Add to cart

5 Guard Available 00H01201331

•

  Covering Cap Piaggio Group · 00H01201331 Available

  € 2,35

  Add to cart

6 CASQ.LADO DISCO DRD PRO 09 Available 866015

•

  Spacer Piaggio Group · 866015 Available

  € 10,97

  Add to cart
•

  Spacer Bush Piaggio Group · 867313 Backorder

  € 64,58

  Add to cart

7 Front/rear tyre 00H01219111 No longer available

• 00H01219111 Front/rear tyre
  No longer available
• 865685 CUBIERTA 80/90X21 M/C 48P MT21(PIR)
  No longer available

8 CAMARA RDA.DT.MA 21 PIRELLI 00H01208101 No longer available

• 00H01208101 CAMARA RDA.DT.MA 21 PIRELLI
  No longer available
• 00H01206101 FRONT TUBE
  No longer available

9 Brake disc Available 865534

•

  Brake Disk front, Ø 260,00 mm Piaggio Group · 865534 Available

  € 119,34

  Add to cart
•

  Brake Disk wave, front, Ø 260,00 mm Piaggio Group · 865801 Available

  € 145,20

  Add to cart

10 M6x20 pre-coated hex head screw Available 2B004560

•

  Screw M6x20 Piaggio Group · 2B004560 Available

  € 1,00

  Add to cart

11 Front wheel 00H01209082 No longer available

• 00H01209082 Front wheel
  No longer available
•

  Rim front Piaggio Group · 00H01209081 Backorder

  € 157,30

  Add to cart

12 Flap 00D01201091 No longer available

• 00D01201091 Flap
  No longer available

13 R-RADIO RUEDA DLNTA.250 X 3,08 00H01209061 No longer available

• 00H01209061 R-RADIO RUEDA DLNTA.250 X 3,08
  No longer available

14 Nut Available 00002212070

•

  Standard nut Piaggio Group · 00002212070 Available

  € 2,47

  Add to cart

15 Spacer kit Available 866745

•

  Bearing kit Piaggio Group · 866745 Available

  € 41,27

  Add to cart

16 Bleeder kit 00H04705121 No longer available

• 00H04705121 Bleeder kit
  No longer available

17 LEFT-HAND FRONT CLIP ASSY 00H01214191 No longer available

• 00H01214191 LEFT-HAND FRONT CLIP ASSY
  No longer available

18 Screw Available 00004014001

•

  Screw Piaggio Group · 00004014001 Available

  € 2,70

  Add to cart

19 Screw Available 00000004160

•

  Screw Piaggio Group · 00000004160 Available

  € 4,37

  Add to cart

20 Brake pads 00H04704141 No longer available

• 00H04704141 Brake pads
  No longer available

21 Spring 00H04700171 No longer available

• 00H04700171 Spring
  No longer available

22 Screw 00H04703171 No longer available

• 00H04703171 Screw
  No longer available

23 Wheel bearing Available 601345

•

  Wheel bearing 6202 2RSH C3, 15x35x11 mm Piaggio Group · 601345 · Quantity needed: 2 Available

  € 14,36

  Add to cart

24 Bushing Available 867072

•

  Standard nut Piaggio Group · 867072 Available

  € 10,66

  Add to cart

25 Spacer 867536 No longer available

• 867536 Spacer
  No longer available
