Exploded view — Flywheel Magneto

Products

1 Stator (CARB) Available 58136R

• • Carburettor version (C364M)


  Alternator Piaggio Group · 58136R Available · Shipped in 3–5 working days

  € 224,73

  Add to cart

  Alternatives from other brands

  Stator WAI · 2770118 Backorder · Shipped in 2–5 weeks

  € 58,55

  Add to cart



  Stator PIAGGIO NRG 50 Athena · S410480394001 Backorder · Shipped in 2–5 weeks

  € 90,75

  Add to cart

2 Stator (Carb) Available 639865

•

  Armature Plate / Stator Plate, Langfang Kokusan Piaggio Group · 639865 Available · Shipped in 3–5 working days

  € 95,86

  Add to cart

  Alternatives from other brands



  Stator PIAGGIO NRG 50 Athena · S410480394001 Backorder · Shipped in 2–5 weeks

  € 90,75

  Add to cart

3 Complete rotor (Kokusan) (Carb.) Available 584526

• • Carburettor version (C364M)


  Flywheel, Langfang Kokusan Piaggio Group · 584526 Available · Shipped in 3–5 working days

  € 89,38

  Add to cart

4 Hose clamp Available 257134

• • Taiwan
  • iGET version


  Cable Ties length: 27,7cm Piaggio Group · 257134 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

5 Screw Available 015856

• • Injection version (C361M)


  Screw M5x21 Piaggio Group · 015856 · Quantity needed: 3 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

6 Screw Available 873979

•

  Screw M5x14 Piaggio Group · 873979 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 1,45

  Add to cart

7 Woodruff key Available 000267

•

  Alternator wedge, 12,6x5x3 Piaggio Group · 000267 Available · Shipped in 3–5 working days

  € 2,77

  Add to cart

8 Flanged nut Available 289005

•

  Standard nut Piaggio Group · 289005 Available · Shipped in 3–5 working days

  € 1,25

  Add to cart
