Exploded view — Driving Pulley

Products

1 Variator Available CM144407

•

  Variator with 6 rollers Piaggio Group · CM144407 Available

  € 101,66

  Add to cart

2 Spacer Available 483889

•

  Converter Hub Piaggio Group · 483889 Available

  € 39,86

  Add to cart

3 Roller contrast Available 842204

•

  Calotte Piaggio Group · 842204 Available

  € 15,22

  Add to cart

5 Pin roller (- 11,2 g) Available 842870

•

  Variator roller 21x17 mm, 12,0 g, Content: 1 Stk Piaggio Group · 842870 · Quantity needed: 6 Available

  € 6,10

  Add to cart

6 Variator slider Available 843028

•

  Slide Piaggio Group · 843028 · Quantity needed: 3 Available

  € 2,80

  Add to cart

7 V-Belt Pulley Available 840193

•

  Pulley halves Piaggio Group · 840193 Available

  € 45,17

  Add to cart

8 V-Belt 82941R No longer available

• 82941R V-Belt
  No longer available

9 Washer Available 434885

•

  Shim Piaggio Group · 434885 Available

  € 2,35

  Add to cart

10 Nut Available 486324

•

  Standard nut M12x1.25 Piaggio Group · 486324 Available

  € 1,31

  Add to cart

11 Washer Available 840533

•

  Shim 12,1x36x2 mm Piaggio Group · 840533 Available

  € 2,57

  Add to cart

12 Belleville spring 0,5x35x17 Available 880950

•

  Cup Spring Piaggio Group · 880950 Available

  € 8,68

  Add to cart

13 Toothed pulley Available 833989

•

  Toothed Belt Pulley Piaggio Group · 833989 Available

  € 74,26

  Add to cart

14 Screw Available 828217

•

  Adjustment Screw Piaggio Group · 828217 Available

  € 1,77

  Add to cart
