Exploded view Carburettor, Assembly - Union Pipe — Vespa LX 50 4T 2007

Products

1 Carburettor Available CM141914

•

  Carburettor Piaggio Group · CM141914 Available · Shipped in 3–5 working days

  € 407,82

  Add to cart

2 Air bellow Available 845489

•

  Fork Dust Cover Piaggio Group · 845489 Available · Shipped in 3–5 working days

  € 31,44

  Add to cart

3 Screw Available 018639

• • 125 cc version
  • Country: Taiwan


  Flanged Screw M6x20 Piaggio Group · 018639 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,77

  Add to cart
•

  Hexagon Screw M6x22 Piaggio Group · 031091 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

4 Intake Manifold Available 845946

• • Type approval ZD4TGB***


  Intake manifold Piaggio Group · 845946 Available · Shipped in 3–5 working days

  € 27,81

  Add to cart

6 Hose clamp Available 257134

• • Taiwan
  • iGET version


  Cable Ties length: 27,7cm Piaggio Group · 257134 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

7 Clamp Available 847778

•

  Clamp Piaggio Group · 847778 Available · Shipped in 3–5 working days

  € 1,59

  Add to cart

8 Clamp Available CM002901

• • Carburettor version (C364M)
  • Injection version (C361M)
  • Year of manufacture: 2012
  • Year of manufacture: 2013
  • Country: Canada
  • Country: United States of America


  Clamping Spring Piaggio Group · CM002901 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

9 Clamp Available CM002904

•

  Clamping Spring Piaggio Group · CM002904 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

10 Clamp Available CM001904

•

  Clamp Piaggio Group · CM001904 Available · Shipped in 3–5 working days

  € 1,72

  Add to cart

11 Clamp Available 1A000833

•

  Clamp Piaggio Group · 1A000833 Available · Shipped in 3–5 working days

  € 10,74

  Add to cart
