Exploded view — Carburettor, Assembly - Union Pipe

Products

1 Carburettor Available 1A003195

• 1A003195 Carburettor
  • Country: Australia


  No description available Piaggio Group · 1A0031956 ↻ Replaces 1A003195, which the manufacturer no longer supplies. Available · Shipped in 3–5 working days

  € 239,07

  Add to cart

2 Intake Manifold Available 1A008824

•

  Intake manifold Piaggio Group · 1A008824 Available · Shipped in 3–5 working days

  € 15,10

  Add to cart

3 Air duct Available 488129

•

  Hose Piaggio Group · 488129 Available · Shipped in 3–5 working days

  € 17,44

  Add to cart

4 Clamp 1A006280 No longer available

• 1A006280 Clamp
  No longer available

5 Screw (M6x22) Available 1A000352

• • Country: Taiwan


  Screw M6x22 Piaggio Group · 1A000352 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 3,71

  Add to cart

6 Clamp Available CM001901

• • Colour: Public Authorities China
  • Country: Canada
  • Country: China
  • Country: United States of America


  Clamp Piaggio Group · CM001901 Available · Shipped in 3–5 working days

  € 2,04

  Add to cart

7 Resistor Module Available 82961R6

•

  Resistor Piaggio Group · 82961R6 Available · Shipped in 3–5 working days

  € 33,64

  Add to cart

8 Lock-strap L=180mm Available 145298

•

  Cable Ties black, length: 18,0cm Piaggio Group · 145298 Available · Shipped in 3–5 working days

  € 1,43

  Add to cart

9 Hood for carburettor Available 832186

•

  Bonnet Piaggio Group · 832186 Available · Shipped in 3–5 working days

  € 19,03

  Add to cart

10 Reed valve Available 82774R

•

  Reed valve Piaggio Group · 82774R Available · Shipped in 3–5 working days

  € 32,50

  Add to cart
