Exploded view — Engine
‹ Back to model
Aprilia RSV 1000 2003
Products
1 Engine
-
AP8176066 Engine
- "R"acing GP1 Limited Ed. version
- Country: United States of America
-
AP8106970 Engine
- RSV Mille "R"acing version
- RSV Mille version
-
AP8176044 Engine
- "R"acing GP1 Limited Ed. version
-
AP8106975 Engine
- RSV Mille "R"acing version
- RSV Mille version
- Country: United States of America
2 Sprocket cover, grey
-
AP8106687 Sprocket cover, greyNo longer available
3 Gear change pedal Available
-
Gear Lever Piaggio Group · AP8106874 Available · Shipped in 3–5 working days€ 79,11
4 Lever rubber Available
-
- Standard rider footrests
Pedal Rubber Piaggio Group · AP8120912 Available · Shipped in 3–5 working days€ 4,51
5 Lever pin Available
-
Bolts Piaggio Group · AP8121221 Available · Shipped in 3–5 working days€ 25,29
6 Seeger Available
-
Circlip Ø 9,00 mm Piaggio Group · AP8150462 Available · Shipped in 3–5 working days€ 1,61
7 Spacer
-
AP8221046 Spacer Quantity needed: 3No longer available
8 Screw Available
-
- Colour: Hot red 02-03
- Colour: Peltro Grey 02-03
- For engines from V4-G 1000 to V4-G 1339
- Up to engine V4-A 1645
- Year of manufacture: 2002
- Country: Denmark
Screw M6x30 Piaggio Group · AP8150220 · Quantity needed: 3 Available · Shipped in 3–5 working days€ 1,21
9 Screw Available
-
- Colour: Tuscany Tibet 2003
- Year of manufacture: 1996
- Year of manufacture: 2009
Screw M6x20 Piaggio Group · AP8150044 · Quantity needed: 2 Available · Shipped in 3–5 working days€ 1,48
10 Oil pipe 6x12 Backorder
-
- Year of manufacture: 2014
Oil Hose Piaggio Group · AP8144015 Backorder · Shipped in 2–4 weeks€ 73,82
11 3-way union Available
-
- California approval
- First series
- Up to frame LL 115274
- Country: Canada
- Country: United States of America
Hose connector Piaggio Group · AP8120116 Available · Shipped in 3–5 working days€ 36,43
12 Clamp Available
-
- Year of manufacture: 2014
- Country: Canada
- Country: China
- Country: United States of America
Hose clamp green, 11x6,6 mm Piaggio Group · AP8120446 · Quantity needed: 3 Available · Shipped in 3–5 working days€ 3,36
13 Anti-return valve Available
-
- California approval
- Country: Europe
- Country: Japan
- Country: United States of America
Valve Piaggio Group · AP8104251 Available · Shipped in 3–5 working days€ 47,34
14 Clamp Available
-
- Colour: Public Authorities China
- Year of manufacture: 2008
- Country: Canada
- Country: China
- Country: United States of America
Clamp Click rose, 11,5x6 mm Piaggio Group · AP8102159 · Quantity needed: 3 Available · Shipped in 3–5 working days€ 10,55
More drawings of this model
View all →
