Exploded view — Lock Hardware Kit

Products

1 Lock kit Available B043920

• B043920 Lock kit


  Lock Set Piaggio Group · 2D000505 ↻ Replaces B043920, which the manufacturer no longer supplies. Available · Shipped in 3–5 working days

  € 612,33

  Add to cart

2 Key blank (with transpo.) Available AP8140711

•

  Key Blank with Transponder, Innenbahnschlüssel Piaggio Group · AP8140711 Available · Shipped in 3–5 working days

  € 85,24

  Add to cart

3 Fuel filler cap and lock Available B043929

•

  Tank Cap Piaggio Group · B043929 Available · Shipped in 3–5 working days

  € 285,08

  Add to cart

4 Pass.saddle connecting plate Available AP8102913

•

  Bracket Piaggio Group · AP8102913 Available · Shipped in 3–5 working days

  € 32,96

  Add to cart

5 Lock cable Available 858955

•

  Bowden cable Piaggio Group · 858955 Available · Shipped in 3–5 working days

  € 16,09

  Add to cart

6 Seat lock with key Available AP8104719

•

  Seat Lock Piaggio Group · AP8104719 Available · Shipped in 3–5 working days

  € 204,96

  Add to cart

7 Main switch - steering lock Available 858580

• 858580 Main switch - steering lock


  Ignition Lock Piaggio Group · 2D000509 ↻ Replaces 858580, which the manufacturer no longer supplies. Available · Shipped in 3–5 working days

  € 579,08

  Add to cart

8 Spacer Available AP8221129

• • New version
  • Country: United States of America


  Sleeve Piaggio Group · AP8221129 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,78

  Add to cart

9 10 - Screw Backorder AP8150285

• • Colour: """GARDA"" Bluevert 2001"
  • Colour: Limited Edition green 2013
  • Colour: Tuscany Tibet 2003
  • Year of manufacture: 1999
  • Country: Europe
  • Country: Germany


  Screw M6x35 Piaggio Group · AP8150285 · Quantity needed: 2 Backorder · Shipped in 2–4 weeks

  € 2,35

  Add to cart

10 Fuel filler cap gasket Available AP8104803

• • Colour: Aprilia black 2004
  • Colour: Fluo Red 2004
  • Factory "R" RSV version
  • RSV Mille "R" version
  • See technical communication no. 33/2003
  • Year of manufacture: 2004


  Gasket Piaggio Group · AP8104803 Available · Shipped in 3–5 working days

  € 29,69

  Add to cart

11 Plate Available AP8134948

•

  Hooks Piaggio Group · AP8134948 Available · Shipped in 3–5 working days

  € 14,85

  Add to cart

12 Lock nut M22x1,5 Available AP8102523

•

  Standard nut Piaggio Group · AP8102523 Available · Shipped in 3–5 working days

  € 10,74

  Add to cart

13 Tool roll Backorder 2B003301

• 2B003301 Tool roll


  Vehicle tool kit Piaggio Group · 2B003365 ↻ Replaces 2B003301, which the manufacturer no longer supplies. Backorder · Shipped in 2–4 weeks

  € 19,82

  Add to cart

14 Op's handbook -J-UK- 894146 No longer available

• 894146 Op's handbook -J-UK-
  No longer available
• 894147 Operator's handbook -i-d-f-e
  No longer available
• 894148 Op's handbook -UK-NL-GR-DK-SF-F-
  No longer available
• 894144 Op's handbook -CA-USA-
  No longer available
