Exploded view — Plate Set

‹ Back to model

Aprilia RX 50 2003

Products

1 Constructor dataplate AP8267611 No longer available

AP8267611 Constructor dataplate
- European approval (Euro 1 limits)
- Limited version 45 km/h
- Supermotard MX 50 version
- Year of manufacture: 2002
- Year of manufacture: 2003
No longer available
AP8277110 Constructor dataplate
- European approval (Euro 2 limits)
- Limited version 45 km/h
- Limited version 45 km/h
No longer available
AP8277329 Constructor dataplate
- European approval (Euro 2 limits)
- Full power version
No longer available
AP8267976 Constructor dataplate
- Year of manufacture: 2003
No longer available

2 Tamperproof dataplate AP8277328 No longer available

AP8277328 Tamperproof dataplate
- European approval (Euro 2 limits)
- Full power version
No longer available
AP8267622 Tamperproof dataplate
- European approval (Euro 1 limits)
- Limited version 45 km/h
- Supermotard MX 50 version
- Year of manufacture: 2002
- Year of manufacture: 2003
No longer available
AP8267975 Tamperproof dataplate
- Year of manufacture: 2003
No longer available
AP8277109 Tamperproof dataplate
- European approval (Euro 2 limits)
- Limited version 45 km/h
- Limited version 45 km/h
No longer available

3 Rivet * Available AP8201457

- Habana Custom version
- Habana Retro version
- Mojito Retro version
Rivet plastic Piaggio Group · AP8201457 · Quantity needed: 2 Available · Shipped in 3–5 working days

€ 4,01
