Exploded view — Frame » Front Body Iv - Front Fairing

‹ Back to model

Aprilia Scarabeo 100 2T (Minarelli) 2000

Products

1 Up. front fairing, mirò red AP8148063 No longer available

AP8148063 Up. front fairing, mirò red
No longer available
AP8148785 Up. front fairing, chips blue
No longer available
AP8149086 Up. front fairing, th.silver
No longer available
Front Shield, black, Manufacturer colour: Aprilia black Piaggio Group · AP8268505 Backorder

€ 285,79
AP8148739 Up. front fairing, reef blue
No longer available
AP8148800 Up. front fairing, chamois
No longer available

2 Screw Available 2B014101

Screw Piaggio Group · 2B014101 · Quantity needed: 4 Available

€ 3,78

3 Screw Available AP8150413

Thread Screw 3,9x14 mm, stainless steel Piaggio Group · AP8150413 · Quantity needed: 2 Available

€ 1,69

4 Clip nuts Available AP8202449

Sheet nut Piaggio Group · AP8202449 · Quantity needed: 2 Available

€ 2,18
