Exploded view Frame » Front Body - Front Fairing — Aprilia Scarabeo 125-200 (Piaggio) 2003

‹ Back to model
Aprilia Scarabeo 125-200 (Piaggio) 2003 Aprilia Scarabeo 125-200 (Piaggio) 2003
Frame » Front Body - Front Fairing

Products

1 Handlebar cover, grey AP8168088 No longer available
  • AP8168088 Handlebar cover, grey
    • Colour: Mercury Grey 2001-2002-2003
    • Colour: Mercury Grey 2003
    • Touring version
    • Year of manufacture: 2002
    • Year of manufacture: 2003
    No longer available
  • AP8168823 Handlebar cover, blue
    • Colour: Main Blue 2003
    • Colour: Main Blue 2005-2006 (s.t.14814-14919)
    • Year of manufacture: 2003
    No longer available
  • AP8168747 Handlebar cover, green
    • Colour: Sideral Green 2003
    • Year of manufacture: 2003
    No longer available
2 Headlight support, grey AP8149887 No longer available
  • AP8149887 Headlight support, grey
    • Colour: Mercury Grey 2001-2002-2003
    • Colour: Mercury Grey 2003
    • Basic version
    • France Touring version
    No longer available
  • AP8168822 Headlight support, blue
    • Colour: Main Blue 2003
    • Basic version
    • Year of manufacture: 2003
    No longer available
    • Colour: Main Blue 2003
    • Colour: Mercury Grey 2001-2002-2003
    • Colour: Mercury Grey 2003
    • Colour: Sideral Green 2003
    • GT version
    • Touring version
    • Year of manufacture: 2002
    • Year of manufacture: 2003
    Handlebar Fairing, black Piaggio Group · AP8168095 Available · Shipped in 3–5 working days
    € 103,18
  • AP8168784 Headlight support, green
    • Colour: Sideral Green 2003
    • Basic version
    • Year of manufacture: 2003
    No longer available
3 Windshield AP8149310 No longer available
  • AP8149310 Windshield
    • Basic version
    • Light version
    • Country: Australia
    • Country: Canada
    • Country: United States of America
    No longer available
  • AP8158981 Windshield
    • Basic version
    • Light version
    • Year of manufacture: 2002
    • Year of manufacture: 2003
    No longer available
4 Screw Available AP8150421
    • Colour: Alitalia (t.s.899864)
    • Colour: Replica Alitalia (t.s.899863)
    • Colour: Replica MY13
    • Colour: Replica SBK MY12
    • Country: Canada
    • Country: Italy
    • Country: United States of America
    Thread Screw 2,9x12 mm, stainless steel Piaggio Group · AP8150421 · Quantity needed: 6 Available · Shipped in 3–5 working days
    € 2,18
5 Rubber w/ insert Available AP8120531
    • Year of manufacture: 1998
    • Year of manufacture: 2003
    Rubber Bush Piaggio Group · AP8120531 · Quantity needed: 4 Available · Shipped in 3–5 working days
    € 7,84
6 Screw Available AP8150413
    • Colour: Alitalia (t.s.899864)
    • Colour: Replica Alitalia (t.s.899863)
    • Colour: Replica MY13
    • Colour: Replica SBK MY12
    Thread Screw 3,9x14 mm, stainless steel Piaggio Group · AP8150413 · Quantity needed: 4 Available · Shipped in 3–5 working days
    € 1,80
7 Screw Available AP8150444
    • ETV Capo Nord Standard version
    • Injection version (C361M)
    • Country: Canada
    • Country: United States of America
    Thread Screw 4x9 mm, stainless steel Piaggio Group · AP8150444 · Quantity needed: 2 Available · Shipped in 3–5 working days
    € 1,48
8 Spacer Available AP8120253
    • Country: United States of America
    Spacer disc Piaggio Group · AP8120253 · Quantity needed: 2 Available · Shipped in 3–5 working days
    € 1,88
9 Screw Available 2B014101
  • Screw Piaggio Group · 2B014101 · Quantity needed: 2 Available · Shipped in 3–5 working days
    € 3,78
10 Cover Backorder AP8148050
    • Basic version
    Lid Piaggio Group · AP8148050 · Quantity needed: 2 Backorder · Shipped in 2–4 weeks
    € 9,73
11 Screw Available AP8152270
    • Colour: Public Authorities China
    Screw M5x25 Piaggio Group · AP8152270 · Quantity needed: 4 Available · Shipped in 3–5 working days
    € 2,18
12 Screw Available AP8152345
  • Oval Head Screw 5,5x20 mm Piaggio Group · AP8152345 · Quantity needed: 2 Available · Shipped in 3–5 working days
    € 1,74
