Exploded view — Frame » Lock Hardware Kit

Products

1 Lock kit Backorder AP8102841

•

  Lock Set Piaggio Group · AP8102841 Backorder · Shipped in 2–4 weeks

  € 152,21

  Add to cart

2 Key blank Available AP8104613

• • Carburettor version (C364M)


  Key blank without transponder Piaggio Group · AP8104613 Available · Shipped in 3–5 working days

  € 19,66

  Add to cart

3 Lock nut M22x1,5 Available AP8102523

•

  Standard nut Piaggio Group · AP8102523 Available · Shipped in 3–5 working days

  € 10,74

  Add to cart

4 Top box lock AP8104584 No longer available

• AP8104584 Top box lock
  No longer available

5 Main switch - steering lock AP8124620 No longer available

• AP8124620 Main switch - steering lock
  No longer available

6 Commutator cap Available AP8102944

•

  Cap Piaggio Group · AP8102944 Available · Shipped in 3–5 working days

  € 6,45

  Add to cart

7 Screw Available AP8152140

•

  Shear / Snap Off Screw M6x17 Piaggio Group · AP8152140 Available · Shipped in 3–5 working days

  € 2,63

  Add to cart

8 Saddle lock Available AP8102945

•

  Seat Lock Piaggio Group · AP8102945 Available · Shipped in 3–5 working days

  € 41,10

  Add to cart

9 Lock cable AP8114381 No longer available

• AP8114381 Lock cable
  No longer available

10 Screw (6x12) Available AP8152277

• • Colour: Royal Hashemite Court
  • Country: Canada
  • Country: Germany
  • Country: United States of America


  Flanged Screw M6x12 Piaggio Group · AP8152277 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,18

  Add to cart

11 Spacer Available AP8121075

• • Year of manufacture: 1996
  • Year of manufacture: 2007


  Sleeve Piaggio Group · AP8121075 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,35

  Add to cart

12 Screw Available 598839

• • Colour: Off Black 2009 (s.t.890773)
  • Colour: Off Black 2010 (s.t.895847)
  • Country: China
  • Country: Japan
  • Country: United States of America


  Flanged Screw M6x16 Piaggio Group · 598839 Available · Shipped in 3–5 working days

  € 1,48

  Add to cart

13 Key blank AP8104598 No longer available

• AP8104598 Key blank
  • Red keyhole
  • Year of manufacture: 2003
  • Year of manufacture: 2004
  No longer available
