Exploded view — Frame » Front Body Ii - Dashboard
‹ Back to model
Aprilia Scarabeo 50 2T (Minarelli) 1998
Products
1 Dashboard panel, s. blue
-
AP8238917 Dashboard panel, s. blueNo longer available
-
AP8248425 Dashboard panel, black varn.No longer available
-
AP8248292 Dashboard panel, blue varn.No longer available
-
AP8239358 Dashboard panel, az.brownNo longer available
-
AP8248276 Dashboard panel, brown varn.No longer available
-
AP8248440 Dashboard panel, cherry redNo longer available
-
AP8239931 Dashboard panel, sky blueNo longer available
-
AP8239630 Dashboard panel, l. brownNo longer available
-
AP8239787 Dashboard panel, lymph greenNo longer available
-
AP8239773 Dashboard panel, ab.greyNo longer available
-
AP8238928 Dashboard panel, whiteNo longer available
-
AP8239857 Dashboard panel, ap. blackNo longer available
2 Screw Available
-
Thread Screw 2,9x12 mm, stainless steel Piaggio Group · AP8150421 · Quantity needed: 4 Available€ 2,18
3 Ap. black plug d14
-
AP8239860 Ap. black plug d14 Quantity needed: 3No longer available
-
AP8239790 Lymph green plug d14 Quantity needed: 3No longer available
-
AP8248428 Plug, black varnished d14 Quantity needed: 3No longer available
-
AP8239934 Sky blue plug d14 Quantity needed: 3No longer available
-
AP8238932 Plug, a.white d14 Quantity needed: 3No longer available
-
AP8238921 Zaphire blue plug d14 Quantity needed: 3No longer available
-
AP8239776 Ab. grey plug d14 Quantity needed: 3No longer available
-
AP8248443 Plug, cherry red d14 Quantity needed: 3No longer available
-
AP8239634 Light brown plug d14 Quantity needed: 3No longer available
