Exploded view — Frame » Front Body Iv - Front Fairing

‹ Back to model

Aprilia Scarabeo 50 2T (Minarelli) 1998

Products

1 Up. front fairing, blue varn. AP8248287 No longer available

AP8248287 Up. front fairing, blue varn.
No longer available
Front Shield, white Piaggio Group · AP8239872 Backorder

€ 271,50
AP8239365 Up. front fairing, az. brown
No longer available
AP8248435 Up. front fairing, cherry red
No longer available
AP8239782 Up. front fairing, lymph green
No longer available
AP8239635 Front cover, light brown
No longer available
AP8239768 Up. front fairing, ab. grey
No longer available
AP8248271 Up. front fairing, brown varn.
No longer available
AP8239926 Up. front fairing, sky blue
No longer available
AP8248420 Up. front fairing, black varn.
No longer available
AP8239873 Up. front fairing, s.blue
No longer available
AP8239852 Up. front fairing, ap. black
No longer available

2 Screw Available 2B014101

Screw Piaggio Group · 2B014101 · Quantity needed: 4 Available

€ 3,78

3 Screw Available AP8150413

Thread Screw 3,9x14 mm, stainless steel Piaggio Group · AP8150413 · Quantity needed: 2 Available

€ 1,69

4 Clip nuts Available AP8202449

Sheet nut Piaggio Group · AP8202449 · Quantity needed: 2 Available

€ 2,18
