Exploded view — Frame » Front Body V - Internal Shield
‹ Back to model
Aprilia Scarabeo 50 2T (Minarelli) 1998
Products
1 Internal shield, ab. grey
-
AP8239774 Internal shield, ab. greyNo longer available
-
AP8239646 Internal shield, blueNo longer available
-
AP8248293 Internal shield, blue varn.No longer available
-
AP8239858 Internal shield, aprilia blackNo longer available
-
AP8239645 Internal shield, whiteNo longer available
-
AP8239932 Internal shield, sky cyanNo longer available
-
AP8239631 Internal shield, light brownNo longer available
-
AP8239788 Internal shield, lymph greenNo longer available
-
AP8248441 Internal shield, cherry redNo longer available
-
AP8239360 Internal shield, az. brownNo longer available
-
AP8248277 Internal shield, brown varn.No longer available
-
AP8248472 Internal shield, black varn.No longer available
-
AP8248426 Internal shield, black varn.No longer available
2 Screw Available
-
Shear / Snap Off Screw M6x17 Piaggio Group · AP8152140 Available€ 2,63
3 Screw Available
-
Thread Screw 3,9x14 mm, stainless steel Piaggio Group · AP8150413 · Quantity needed: 4 Available€ 1,69
4 Type appr.data cover, grey
-
AP8231478 Type appr.data cover, greyNo longer available
-
AP8248429 Appr.data cov., black varn.No longer available
-
AP8248455 Appr.data cov., brown varn.No longer available
-
AP8239961 Type appr.data cover, blackNo longer available
-
AP8239960 Type appr.data cover, l.brownNo longer available
-
AP8248456 Appr.data cov., blue varn.No longer available
-
AP8248444 Appr.data cov., cherry redNo longer available
5 Screw Available
-
Screw Piaggio Group · 2B014101 Available€ 3,78
6 Key blank Available
-
Key blank without transponder Piaggio Group · AP8104613 Available€ 19,66
7 Screw Available
-
Screw M6x16 Piaggio Group · AP8150137 Available€ 1,48
8 Main switch - steering lock Available
-
Steering Lock Piaggio Group · AP8201793 Available€ 96,00
9 Gyújtáskapcsoló keret Available
-
Gasket Piaggio Group · AP8220386 Available€ 8,74
