Exploded view — Ignition Unit

Products

1 Starter motor AP8224103 No longer available

• AP8224103 Starter motor
  No longer available

2 Washer AP8206206 No longer available

• AP8206206 Washer Quantity needed: 2
  No longer available

3 Idle gear plate AP8206700 No longer available

• AP8206700 Idle gear plate
  No longer available

4 Idle gear + bush AP8206665 No longer available

• AP8206665 Idle gear + bush
  No longer available

5 Pin D8x32 Available AP8206172

•

  Bolts Piaggio Group · AP8206172 Available

  € 11,97

  Add to cart

6 Ignition coil AP8206125 No longer available

• AP8206125 Ignition coil
  No longer available

7 CDI unit AP8206470 No longer available

• AP8206470 CDI unit
  No longer available

8 Spark plug cap AP8212709 No longer available

• AP8212709 Spark plug cap
  No longer available

9 Screw AP8502564 No longer available

• AP8502564 Screw
  No longer available

10 Screw AP8206202 No longer available

• AP8206202 Screw Quantity needed: 2
  No longer available

11 Brush holder with OR Backorder AP8224093

•

  Brush Holder Piaggio Group · AP8224093 Backorder

  € 82,73

  Add to cart
