Exploded view — ABS System
‹ Back to model
Aprilia SR GT 400 E5+ 2026
Products
1 Canister Available
-
Charcoal Filter Piaggio Group · 1B003695 Available · Shipped in 3–5 working days€ 84,59
2 Canister support Available
-
Clamp Piaggio Group · 1B003721 · Quantity needed: 2 Available · Shipped in 3–5 working days€ 4,59
3 Sae j30 pipe Available
-
Hose SAE J30 R7/R14 T2 Inch: 3/16\" Piaggio Group · CM183403 Available · Shipped in 3–5 working days€ 25,31
4 Pressure valve Available
-
Pressure Valve Piaggio Group · CM292102 Available · Shipped in 3–5 working days€ 44,07
5 Tube Available
-
CM001405 TubeBreather Pipe length: 1,06m Piaggio Group · CM001432 ↻ Replaces CM001405, which the manufacturer no longer supplies. Available · Shipped in 3–5 working days€ 13,29
6 Sae j30 pipe R11 1/4" L=250"
-
CM275901 Sae j30 pipe R11 1/4" L=250"No longer available
7 Complete air solenoid valve Available
-
Solenoid valve Piaggio Group · 1B008603 Available · Shipped in 3–5 working days€ 77,46
8 1B013637 Backorder
-
Pipe Piaggio Group · 1B013637 Backorder · Shipped in 2–4 weeks€ 37,51
9 Nut Available
-
Standard nut Piaggio Group · 020206 Available · Shipped in 3–5 working days€ 1,79
10 Washer Available
-
Washer 6,4x11,8x1 mm Piaggio Group · 016406 Available · Shipped in 3–5 working days€ 1,79
11 TUBO SAE J30R7/R14T2 1/4 L.480 Backorder
-
TUBO SAE J30R7/R14T2 1/4 L.480 Piaggio Group · CM183307 Backorder · Shipped in 2–4 weeks€ 26,29
12 Wiring clip Backorder
-
Clamp Piaggio Group · 1B001321 Backorder · Shipped in 2–4 weeks€ 4,74
13 Screw Available
-
Screw M6x16 Piaggio Group · CM179301 Available · Shipped in 3–5 working days€ 1,48
14 Clamp Available
-
Clamp Piaggio Group · CM001914 · Quantity needed: 6 Available · Shipped in 3–5 working days€ 1,65
15 Hose Clamp Available
-
CM001912 Hose ClampClamp Piaggio Group · CM0019126 ↻ Replaces CM001912, which the manufacturer no longer supplies. Available · Shipped in 3–5 working days€ 1,82
16 Clamp Available
-
Clamp Piaggio Group · CM001901 Available · Shipped in 3–5 working days€ 2,04
17 Gasket Available
-
CM017710 GasketGasket length: 12,0cm Piaggio Group · CM017718 ↻ Replaces CM017710, which the manufacturer no longer supplies. Available · Shipped in 3–5 working days€ 5,03
18 1B013619 Backorder
-
Bracket Piaggio Group · 1B013619 Backorder · Shipped in 2–4 weeks€ 4,23
19 1A028473 Backorder
-
Vent pipe Piaggio Group · 1A028473 Backorder · Shipped in 2–4 weeks€ 6,93
20 Lock-strap L=180mm Available
-
Cable Ties black, length: 18,0cm Piaggio Group · 145298 Available · Shipped in 3–5 working days€ 1,43
21 Pipes/cables retainer spring Available
-
Clip Piaggio Group · CM006913 Available · Shipped in 3–5 working days€ 4,19
22 Elastic spring Available
-
Clip Piaggio Group · 231590 Available · Shipped in 3–5 working days€ 0,99
