Exploded view — Front Mudguard-pillar
‹ Back to model
Aprilia Tuono V4 1100 E5 2021
Products
1 Pillar Available
-
- Without decals
Radiator Cover Piaggio Group · 2B008104 Available · Shipped in 3–5 working days€ 99,29
2 Black p. RH lower fairing
-
2B008105000NI Black p. RH lower fairing
- Colour: Painted
- Painted
- Without decals
-
- Colour: Not painted
- Colour: Unpainted
- Not painted
- Without decals
Fairing, right Piaggio Group · 2B008105 Available · Shipped in 3–5 working days€ 119,14
3 Black p. LH lower fairing
-
2B008106000NI Black p. LH lower fairing
- Colour: Painted
- Painted
- Without decals
-
- Colour: Not painted
- Colour: Unpainted
- Not painted
- Without decals
Fairing, left Piaggio Group · 2B008106 Available · Shipped in 3–5 working days€ 119,14
4 Front mudguard Available
-
- Colour: Speed white
- Colour: Time Attack
- Colour: Ultra Gold
- Without decals
Mudguard front Piaggio Group · 2B008635 Available · Shipped in 3–5 working days€ 79,45
5 Reflector, orange Available
-
AP8224163 Reflector, orange Quantity needed: 2
- 200 cc version
- Version with catalytic converter
- Australia
Reflector for plugging in, round, yellow Piaggio Group · Ap8224163 Available · Shipped in 3–5 working days€ 12,08Reflector for plugging in, round, yellow Piaggio Group · Ap8224163 Available · Shipped in 3–5 working days€ 12,08Reflector for plugging in, round, yellow Piaggio Group · AP8224163 Available · Shipped in 3–5 working days€ 12,08
6 Nut Available
-
AP8152306 Nut Quantity needed: 2Nut M5 Piaggio Group · AP81523066 ↻ Replaces AP8152306, which the manufacturer no longer supplies. Available · Shipped in 3–5 working days€ 2,00
7 Screw Available
-
Screw M5x9 Piaggio Group · AP8150500 · Quantity needed: 12 Available · Shipped in 3–5 working days€ 2,47
8 Washer (spring) Available
-
- Colour: Tuscany Tibet 2003
- Year of manufacture: 2012
- Year of manufacture: 2013
- Country: Japan
- Country: United States of America
Shim 8,5x15x0,8 mm Piaggio Group · AP8150376 · Quantity needed: 4 Available · Shipped in 3–5 working days€ 2,04
9 Spacer Available
-
Washer Piaggio Group · 843213 Available · Shipped in 3–5 working days€ 1,48
10 Clip nuts (M5) Available
-
Sheet nut M5 Piaggio Group · AP8102375 · Quantity needed: 9 Available · Shipped in 3–5 working days€ 2,47
11 Screw Available
-
- New fastening
- Version with ARAS
Screw M5x12 Piaggio Group · 896174 Available · Shipped in 3–5 working days€ 2,77
