Exploded view — Frame
‹ Back to model
Derbi Boulevard 50 2T 2009
Products
1 Lower spoiler nero Available
-
Spoiler, black, dyed Piaggio Group · 621984000C Available€ 112,01
2 Rear body side L.H.
-
62198600R7 Rear body side L.H.No longer available
-
6219860090 Rear body side L.H.No longer available
-
Side Fairing, left, white, Suffix: 87_white optic 724 Piaggio Group · 6219860087 Available€ 316,67
-
Side Fairing, left, green, Suffix: XV4_green urban 318/A Piaggio Group · 62198600XV4 Backorder€ 253,34
3 Lower side panel l.h.
-
621990000D Lower side panel l.h.No longer available
-
621990000C Lower side panel l.h.No longer available
4 Rear body side R.H. Available
-
Side Fairing, right, red, Suffix: R7_red dragon / passione / 894 Piaggio Group · 62198700R7 Available€ 253,34
-
Side Fairing, right, green, Suffix: XV4_green urban 318/A Piaggio Group · 62198700XV4 Backorder€ 253,34
-
Side Fairing, right, black, Suffix: 90_black shiny 094 Piaggio Group · 6219870090 Available€ 316,67
-
Side Fairing, right, white, Suffix: 87_white optic 724 Piaggio Group · 6219870087 Available€ 253,34
5 Lower side panel r.h.
-
621991000C Lower side panel r.h.No longer available
-
621991000D Lower side panel r.h.No longer available
6 Guard Backorder
-
Protection piece Piaggio Group · 623021 Backorder€ 14,16
7 Screw (M6x16) Available
-
Screw M6 Piaggio Group · 575249 Available€ 0,99
8 Screw Available
-
Sheet Metal Screw Piaggio Group · 297498 Available€ 0,99
9 Screw Available
-
Screw 3,8x16 mm Piaggio Group · 270793 Available€ 0,99
10 Clip nuts (M6) Available
-
Sheet nut Piaggio Group · 254485 Available€ 2,04
12 Clip nuts Available
-
Sheet nut Piaggio Group · CM017410 Available€ 0,99
14 Screw (4,2x19) Available
-
Sheet Metal Screw Piaggio Group · 258249 Available€ 0,99
16 Screw Available
-
Screw 4,2x13 mm Piaggio Group · 259349 Available€ 0,99
17 Adhesive dataplate "Boulevard TWO" Available
-
Decal, motive: Boulevard Two Piaggio Group · 8662530001 · Quantity needed: 2 Available€ 7,72
-
Decal, motive: Boulevard Two Piaggio Group · 8662530002 · Quantity needed: 2 Available€ 7,72
