Exploded view — Water Pump

‹ Back to model
Derbi GP 50 2002 Derbi GP 50 2002
Water Pump

Products

01 Wheel hub cover with U.P. Available 4874805
02 Nut hold cap Available 1C004746
  • Covering Cap Piaggio Group · 1C004746 Available
    € 3,94
03 Nut Available 563728
  • Standard nut Piaggio Group · 563728 Available
    € 2,77
04 Flat washer Available 159347
  • Washer Piaggio Group · 159347 Available
    € 2,70
05 Pin, split Available 012789
  • Split Pin Piaggio Group · 012789 Available
    € 1,66
07 Driven pulley shaft Available 4795715
08 Gasket ring Available 480066
09 Seeger Available 480953
  • Snap-in Ring Piaggio Group · 480953 Available
    € 1,65
10 Bearing Available 435363
11 Shim washer Available 288639
  • Washer Piaggio Group · 288639 Available
    € 0,99
12 Transmission shaft Available 4784925
13 Screw Available 1A011120
14 Drive shaft assy Available 4874845
15 Gasket ring Available 478498
  • Shaft Seal Piaggio Group · 478498 Available
    € 6,98
16 Seeger Available 006647
17 Bearing Available 434735
18 Screw Available 031091
19 Cable harness Backorder 639856
20 Starter motor Available 82530R
  • Starter Motor Piaggio Group · 82530R Available
    € 116,16
21 Starter bendix gear Available 82958R
22 Kick starter shaft Available 831458
23 Starter lever return spring Available 289495
24 Kick starter lever Available 286214
25 Guard Available 286217
  • Pedal Rubber Piaggio Group · 286217 Available
    € 32,20
26 Seeger Available 288041
  • Locking Ring Piaggio Group · 288041 Available
    € 2,77
27 Washer Backorder 286219
28 Kick starter lever Available 286214
29 Cover Available 483859
  • Lid Piaggio Group · 483859 Available
    € 2,49
30 Screw Available B016774
31 Seeger Available 006416
  • Locking Ring Piaggio Group · 006416 Available
    € 1,65
32 Washer Available 433987
33 Screw Available 269755
  • Screw M8x12 Piaggio Group · 269755 Available
    € 1,59
34 Washer Available 485703
35 Gasket ring Available 827085
36 Complete oil level dipstick Available 832130
  • Oil dipstick Piaggio Group · 832130 Available
    € 6,34

More drawings of this model

View all →
