Exploded view — Front Fork

Products

1 Front fork 00H00235001 No longer available

• 00H00235001 Front fork
  • From chassis 6H309788
  • Marzocchi brand
  No longer available

2 Plug Available 861627

• • From chassis 6H309788
  • Marzocchi brand


  Lock Piaggio Group · 861627 Available · Shipped in 3–5 working days

  € 65,84

  Add to cart

3 Fork upper plate 861628 No longer available

• 861628 Fork upper plate
  • From chassis 6H309788
  • Marzocchi brand
  No longer available

4 Sleeve plug Backorder AP8123348

•

  Screw Plug Piaggio Group · AP8123348 Backorder · Shipped in 2–4 weeks

  € 82,53

  Add to cart

5 O-Ring Backorder 00H00206501

• • From chassis 6H309788
  • Marzocchi brand


  O-Ring Piaggio Group · 00H00206501 Backorder · Shipped in 2–4 weeks

  € 10,74

  Add to cart

6 Half ring Backorder 00H00200721

• • From chassis 6H309788
  • Marzocchi brand


  Semiring Piaggio Group · 00H00200721 Backorder · Shipped in 2–4 weeks

  € 22,81

  Add to cart

7 Stem base 861629 No longer available

• 861629 Stem base
  • From chassis 6H309788
  • Marzocchi brand
  No longer available

8 Screw 861630 No longer available

• 861630 Screw
  • Derbi/Marzocchi fork
  • From chassis 6H309788
  • Marzocchi brand
  • Year of manufacture: 2006
  No longer available

9 Sleeve 861631 No longer available

• 861631 Sleeve
  • From chassis 6H309788
  • Marzocchi brand
  No longer available

10 Bush Available 00H00210151

• • From chassis 6H309788
  • Marzocchi brand


  Slide Bushing Piaggio Group · 00H00210151 Available · Shipped in 3–5 working days

  € 91,92

  Add to cart

11 Ring Available 00H00201441

• • Derbi/Marzocchi fork
  • From chassis 6H309788
  • Marzocchi brand
  • Year of manufacture: 2006


  Oil seal Piaggio Group · 00H00201441 Available · Shipped in 3–5 working days

  € 20,28

  Add to cart

12 Fork oil seal (Marzocchi) Available 599501

• • Marzocchi


  Oil seal Piaggio Group · 599501 Available · Shipped in 3–5 working days

  € 30,29

  Add to cart

  Alternatives from other brands



  Front Fork Seal Set 40x52x10/10.5 Athena · P40FORK455050 Available · Shipped in 4–7 working days

  € 9,72

  Add to cart

13 Stop ring 599503 No longer available

• 599503 Stop ring
  • Marzocchi
  No longer available

14 Fork dust seal (Marzocchi) Available 599502

• • Marzocchi


  Dust guard Piaggio Group · 599502 Available · Shipped in 3–5 working days

  € 26,34

  Add to cart

15 Hub+RH fork leg 861632 No longer available

• 861632 Hub+RH fork leg
  • From chassis 6H309788
  • Marzocchi brand
  No longer available

16 Hub+LH fork leg Backorder 861633

• • From chassis 6H309788
  • Marzocchi brand


  Front Forks left Piaggio Group · 861633 Backorder · Shipped in 2–4 weeks

  € 363,00

  Add to cart

17 Ring spring Available AP8123357

•

  Spacer Ring Piaggio Group · AP8123357 Available · Shipped in 3–5 working days

  € 14,35

  Add to cart

18 Washer Available 861634

• • From chassis 6H309788
  • Marzocchi brand


  Washer Piaggio Group · 861634 Available · Shipped in 3–5 working days

  € 9,68

  Add to cart

19 Spacer 861635 No longer available

• 861635 Spacer
  • From chassis 6H309788
  • Marzocchi brand
  No longer available

20 Screw Available 00H00200831

• • Derbi/Marzocchi fork
  • From chassis 6H309788
  • Marzocchi brand
  • Year of manufacture: 2006


  Screw Piaggio Group · 00H00200831 Available · Shipped in 3–5 working days

  € 6,24

  Add to cart

21 Screw 861636 No longer available

• 861636 Screw
  • From chassis 6H309788
  • Marzocchi brand
  No longer available
