Exploded view — Variator Assembly

Products

1 Variator (250 - 300) Available CM1444085

•

  Variator with 6 rollers Piaggio Group · CM1444085 Available

  € 101,69

  Add to cart

2 Variator slider Available 843028

•

  Slide Piaggio Group · 843028 · Quantity needed: 3 Available

  € 2,80

  Add to cart

3 Pin roller (13,3 g) Available 849480

•

  Variator roller 21x17 mm, 13,8 g, Content: 1 Stk Piaggio Group · 849480 Available

  € 3,81

  Add to cart

4 Roller housing back plate Available 485710

•

  Calotte Piaggio Group · 485710 Available

  € 15,22

  Add to cart

5 Spacer Available 483889

•

  Converter Hub Piaggio Group · 483889 Available

  € 39,86

  Add to cart

6 V-Belt Pulley Available 840193

•

  Pulley halves Piaggio Group · 840193 Available

  € 45,17

  Add to cart

7 Washer Available 434885

•

  Shim Piaggio Group · 434885 Available

  € 2,35

  Add to cart

8 Washer (22x12,1x19) Available 274246

•

  Washer 22x12,1x1 mm Piaggio Group · 274246 Available

  € 1,26

  Add to cart

9 Nut Available 486324

•

  Standard nut M12x1.25 Piaggio Group · 486324 Available

  € 1,31

  Add to cart

10 Bearing Available 82577R

•

  Bearing 10x35x11 mm Piaggio Group · 82577R Available

  € 13,77

  Add to cart

11 V-Belt Available B013360

•

  V-Belt Piaggio Group · B013360 Available

  € 116,66

  Add to cart

12 Screw Available 829326

•

  Screw Piaggio Group · 829326 Available

  € 6,73

  Add to cart

13 Toothed pulley Available 833989

•

  Toothed Belt Pulley Piaggio Group · 833989 Available

  € 74,26

  Add to cart
