Exploded view — Voltage Regulators - Electronic Control Units (ecu) - H.t. Coil

Products

1 Voltage regulator Available 639110

•

  Regulator Piaggio Group · 639110 Available · Shipped in 3–5 working days

  € 204,45

  Add to cart

  Alternatives from other brands



  Voltage Regulator / Rectifier WAI · PMC1002 Available · Shipped in 4–7 working days

  € 97,65

  Add to cart



  Voltage Regulator PIAGGIO Tourmax · RGU701 Available · Shipped in 4–7 working days

  € 121,00

  Add to cart



  REGULATOR, 67 3916 GHMparts · ESR916 Available · Shipped in 4–7 working days

  € 146,35

  Add to cart

2 Screw Available B011784

•

  Screw Piaggio Group · B011784 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,60

  Add to cart

9 Ignition coil Available 58120R

• • 400 cc version
  • 500 cc version


  Ignition Coil Piaggio Group · 58120R Available · Shipped in 3–5 working days

  € 59,25

  Add to cart

10 H.T COIL BRACKET Backorder 640591

•

  Bracket Piaggio Group · 640591 Backorder · Shipped in 2–4 weeks

  € 19,74

  Add to cart

11 Protection collar Available 436919

• • 400 cc version
  • 500 cc version


  Protection piece Piaggio Group · 436919 Available · Shipped in 3–5 working days

  € 2,47

  Add to cart

12 End cap Available 015014

•

  Cable Lugs Piaggio Group · 015014 Available · Shipped in 3–5 working days

  € 1,72

  Add to cart

13 Spark plug cap Available 293845

• • 400 cc version
  • 500 cc version


  Spark Plug Connector Piaggio Group · 293845 Available · Shipped in 3–5 working days

  € 27,37

  Add to cart
•

  Cap Piaggio Group · 071671 Available · Shipped in 3–5 working days

  € 4,08

  Add to cart

14 H.V. cable Available 080341

• • Taiwan


  Ignition Lead Piaggio Group · 080341 Available · Shipped in 3–5 working days

  € 3,88

  Add to cart

15 Bracket Backorder 584772

•

  Bracket Piaggio Group · 584772 Backorder · Shipped in 2–4 weeks

  € 15,27

  Add to cart

19 Screw Available 583236

•

  Screw M3x20 Piaggio Group · 583236 · Quantity needed: 4 Available · Shipped in 3–5 working days

  € 1,48

  Add to cart

20 Washer Available 012554

•

  Washer Piaggio Group · 012554 · Quantity needed: 4 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

21 Nut Available 020003

• • Enjoy 2015


  Standard nut M3 Piaggio Group · 020003 · Quantity needed: 4 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

22 Voltage regulator support 6406155 No longer available

• 6406155 Voltage regulator support
  No longer available

24 Washer Backorder 006125

• • 70° version
  • Touring


  Washer Piaggio Group · 006125 · Quantity needed: 2 Backorder · Shipped in 2–4 weeks

  € 1,75

  Add to cart

25 Nut Available 288245

• • Taiwan version


  Collar nut M6 Piaggio Group · 288245 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

26 Screw Available 031117

•

  Screw M8x18 Piaggio Group · 031117 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,77

  Add to cart

27 Washer (spring) Available 016408

•

  Spring Washer 13,75x8,15x4,5 mm Piaggio Group · 016408 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 1,84

  Add to cart

28 Washer Available 003038

•

  Shim 8,4x18x2 mm Piaggio Group · 003038 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 1,43

  Add to cart

29 Clip nuts (M6) Available 254485

• • Year of manufacture: 2012
  • Year of manufacture: 2013


  Sheet nut Piaggio Group · 254485 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,04

  Add to cart

30 Screw Available B016777

• • ABS version


  Flanged Screw M6x16 Piaggio Group · B016777 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 1,48

  Add to cart
