Exploded view — Cooling System

Products

1 Radiator - water cooler 299389 No longer available

• 299389 Radiator - water cooler
  No longer available

2 Clip nuts (M6) Available 254485

•

  Sheet nut Piaggio Group · 254485 · Quantity needed: 2 Available

  € 2,04

  Add to cart

3 Screw Available 272836

•

  Screw M6x16 Piaggio Group · 272836 · Quantity needed: 4 Available

  € 1,39

  Add to cart

4 Coolant tank Available 656538

•

  Expansion Tank Piaggio Group · 656538 Available

  € 78,38

  Add to cart

5 Tank cap Available 623673

•

  Tank Cap Piaggio Group · 623673 Available

  € 19,66

  Add to cart

6 Clip nuts Available CM017410

•

  Sheet nut Piaggio Group · CM017410 Available

  € 0,99

  Add to cart

7 Screw (4,2x19) Available 258249

•

  Sheet Metal Screw Piaggio Group · 258249 Available

  € 0,99

  Add to cart

8 Upper rubber Available 351782

•

  Buffer Piaggio Group · 351782 · Quantity needed: 2 Available

  € 2,67

  Add to cart

10 Radiator big end connection pipe Backorder 949461

•

  Radiator hose Piaggio Group · 949461 Backorder

  € 49,78

  Add to cart

11 Water hose Available 624252

•

  Radiator hose Piaggio Group · 624252 Available

  € 57,78

  Add to cart

12 Clamp Available CM001905

•

  Hose Clamp Piaggio Group · CM001905 · Quantity needed: 3 Available

  € 1,82

  Add to cart

13 Clamp Available CM001909

•

  Hose Clamp Piaggio Group · CM001909 Available

  € 2,18

  Add to cart

14 Non return spring Available CM006902

•

  Clamp Piaggio Group · CM006902 Available

  € 2,06

  Add to cart

16 Clamp CM001902 No longer available

• CM001902 Clamp Quantity needed: 2
  No longer available

17 Clamp Available CM001904

•

  Clamp Piaggio Group · CM001904 · Quantity needed: 2 Available

  € 1,72

  Add to cart

18 Cooler-tank return pipe Backorder CM007013

•

  Return Pipe Piaggio Group · CM007013 Backorder

  € 28,28

  Add to cart

19 Gasket ring Available 620737

•

  Filler cap seal Piaggio Group · 620737 Available

  € 2,60

  Add to cart

21 Radiator support bracket Available 949370

•

  Bracket Piaggio Group · 949370 Available

  € 19,74

  Add to cart

24 Lock-strap L=180mm Available 145298

•

  Cable Ties black, length: 18,0cm Piaggio Group · 145298 Available

  € 1,43

  Add to cart

25 Hose clamp Available 257134

•

  Cable Ties length: 27,7cm Piaggio Group · 257134 Available

  € 0,99

  Add to cart

26 RETURN RADIATOR/EXPANSION TANK PIPE 949462 No longer available

• 949462 RETURN RADIATOR/EXPANSION TANK PIPE
  No longer available
