Exploded view — Front Body - Front Mudguard

Products

1 Plate Available GU32494010

• • Factory version
  • Municipal police
  • Strada version


  Plate Piaggio Group · GU32494010 Available · Shipped in 3–5 working days

  € 149,60

  Add to cart

2 Front mudguard, azure 977457 No longer available

• 977457 Front mudguard, azure
  • Colour: Cyan 2006
  • Year of manufacture: 2006
  No longer available
• GU32434310 Front mudguard
  • Colour: Unpainted
  No longer available
• GU32434314 Front mudguard (Red)
  • Colour: Race Red 2005
  • Colour: Race Red 2006
  No longer available
• GU32434381 Front mudguard
  • Colour: Public Authorities Mauritius
  No longer available
• 977312 Front mudguard
  • Colour: Guzzi Black 2006
  • Colour: Guzzi Black/Light Grey 2007
  • Year of manufacture: 2006
  • Year of manufacture: 2007
  No longer available

3 Bush Backorder GU91120812

•

  Sleeve Piaggio Group · GU91120812 · Quantity needed: 4 Backorder · Shipped in 2–4 weeks

  € 5,61

  Add to cart

4 Screw (M8x25) Available GU98370825

•

  Screw M8x25 Piaggio Group · GU98370825 · Quantity needed: 4 Available · Shipped in 3–5 working days

  € 5,20

  Add to cart

5 Pillar Available GU32570510

•

  Spoiler Piaggio Group · GU32570510 Available · Shipped in 3–5 working days

  € 42,89

  Add to cart

6 Air intake grid Backorder GU32571510

•

  Ventilation Grill Piaggio Group · GU32571510 Backorder · Shipped in 2–4 weeks

  € 22,32

  Add to cart

7 Screw Available AP8152339

• • Country: Australia


  Flanged Screw M5x9 Piaggio Group · AP8152339 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,35

  Add to cart

8 Clip nuts (M5) Available AP8102375

•

  Sheet nut M5 Piaggio Group · AP8102375 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,47

  Add to cart

9 Screw Available AP8150420

• • Habana Retro version
  • Mojito Retro version


  Thread Screw stainless steel Piaggio Group · AP8150420 · Quantity needed: 5 Available · Shipped in 3–5 working days

  € 2,18

  Add to cart

10 Splash guard GU32436910 No longer available

• GU32436910 Splash guard
  No longer available
• • Colour: Public Authorities Mauritius


  Splash guard Piaggio Group · 884177 Backorder · Shipped in 2–4 weeks

  € 121,00

  Add to cart

11 Fixing pin Available AP8144109

• • Year of manufacture: 1998
  • Year of manufacture: 2003
  • Country: United States of America


  Pin Piaggio Group · AP8144109 Available · Shipped in 3–5 working days

  € 10,48

  Add to cart

12 Washer for shafts D5 (D5) Available AP8150450

• • Colour: Alitalia (t.s.899864)
  • Colour: Replica Alitalia (t.s.899863)
  • Colour: Replica MY13
  • Colour: Replica SBK MY12
  • Country: Canada
  • Country: United States of America


  Waved Washer Ø 5,00 mm Piaggio Group · AP8150450 Available · Shipped in 3–5 working days

  € 2,47

  Add to cart
