Exploded view Side Cases — Moto Guzzi California Stone 1100 2002

Products

1 Suitcase kit 40 L GU03480050 No longer available

• GU03480050 Suitcase kit 40 L
  • See spare parts communication no. 015 of 2001
  No longer available
• GU03480051 Suitcase kit 30 L
  • See spare parts communication no. 015 of 2001
  No longer available

2 RH suitcase 30 L Backorder GU31482565

•

  Side case, 30 l, right, black Piaggio Group · GU31482565 Backorder · Shipped in 2–4 weeks

  € 302,50

  Add to cart
•

  Side case, right Piaggio Group · GU30482560 Backorder · Shipped in 2–4 weeks

  € 266,20

  Add to cart

3 LH suitcase 40 L GU30485760 No longer available

• GU30485760 LH suitcase 40 L
  No longer available
•

  Side case, left, black Piaggio Group · GU31485765 Backorder · Shipped in 2–4 weeks

  € 302,50

  Add to cart

4 "MotoGuzzi" dec. 45 L Backorder GU03482000

• • Touring version


  Emblem, motive: Moto Guzzi Piaggio Group · GU03482000 · Quantity needed: 2 Backorder · Shipped in 2–4 weeks

  € 52,44

  Add to cart

5 RH support Backorder GU03485070

• • Touring version


  Side Case carrier Seitenkofferträger right Piaggio Group · GU03485070 Backorder · Shipped in 2–4 weeks

  € 108,90

  Add to cart

6 LH support Backorder GU03486570

• • Touring version


  Side Case carrier Seitenkofferträger left Piaggio Group · GU03486570 Backorder · Shipped in 2–4 weeks

  € 108,90

  Add to cart

7 Screw Available GU98690440

• • Old
  • See spare parts communication no. 016 of 2001


  Screw M8x40 Piaggio Group · GU98690440 · Quantity needed: 4 Available · Shipped in 3–5 working days

  € 2,89

  Add to cart

8 Washer 8,4X15X1,5 Available GU95008208

•

  Shim 8,4x15x1,8 mm Piaggio Group · GU95008208 · Quantity needed: 6 Available · Shipped in 3–5 working days

  € 1,48

  Add to cart

9 Name plate Kg.10 Backorder GU29482400

• • Stone Touring version
  • Touring version


  Decal, motive: 10 KG Piaggio Group · GU29482400 · Quantity needed: 2 Backorder · Shipped in 2–4 weeks

  € 3,82

  Add to cart

10 Screw Available GU98350318

•

  Screw M6x18 Piaggio Group · GU98350318 · Quantity needed: 4 Available · Shipped in 3–5 working days

  € 1,26

  Add to cart

11 Nut (Lock) Available GU92630707

• • First series
  • Rider footrests set back
  • Touring version
  • Year of manufacture: 2006
  • Year of manufacture: 2007


  Standard nut Piaggio Group · GU92630707 · Quantity needed: 4 Available · Shipped in 3–5 working days

  € 2,31

  Add to cart

12 Lock GU03484000 No longer available

• GU03484000 Lock Quantity needed: 2
  • Stone Touring version
  • Touring version
  No longer available

13 Lock GU03484001 No longer available

• GU03484001 Lock Quantity needed: 4
  • Stone Touring version
  • Touring version
  No longer available

14 Lock plate GU00979726 No longer available

• GU00979726 Lock plate Quantity needed: 2
  • See spare parts communication no. 008 of 2001
  • Stone Touring version
  • Touring version
  No longer available

15 Screw Available GU98690445

• • New
  • See spare parts communication no. 016 of 2001


  Screw M8x45 Piaggio Group · GU98690445 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 3,21

  Add to cart
