Exploded view — Front Wheel

Products

1 Front wheel spindle Front Available 887566

•

  Wheel Axle front Piaggio Group · 887566 Available

  € 54,66

  Add to cart

2 Right front wheel spacer Available 887578

•

  Spacer right Piaggio Group · 887578 Available

  € 38,03

  Add to cart

3 Front LH wheel spacer Available 887579

•

  Spacer left Piaggio Group · 887579 Available

  € 38,03

  Add to cart

4 Screw Available GU98680445

•

  Screw M8x45 Piaggio Group · GU98680445 Available

  € 1,29

  Add to cart

5 Washer 8,4x14,57x1,6 Available GU95005308

•

  Shim 8,4x14,57x1,6 mm Piaggio Group · GU95005308 Available

  € 1,48

  Add to cart

6 Phonic wheel 887875 No longer available

• 887875 Phonic wheel
  No longer available

7 Brake disc Available 887439

•

  Brake Disk front, right Piaggio Group · 887439 Available

  € 179,83

  Add to cart

8 Brake disc Available 887430

•

  Brake Disk front, left Piaggio Group · 887430 Available

  € 179,83

  Add to cart

9 Tone wheel protection Backorder B063440

•

  Protection piece Piaggio Group · B063440 Backorder

  € 11,39

  Add to cart

10 Front wheel(complete) Backorder 2B001948

•

  Rim complete front Piaggio Group · 2B001948 Backorder

  € 1.505,11

  Add to cart

11 Cp. front wheel hub Backorder 2B001233

•

  Hub front Piaggio Group · 2B001233 Backorder

  € 458,76

  Add to cart

12 Front wheel ins.spacer Backorder 887429

•

  Spacer Bush Piaggio Group · 887429 Backorder

  € 35,89

  Add to cart

13 Snap ring d47 Available AP8125842

•

  Snap-in Ring Piaggio Group · AP8125842 Available

  € 0,99

  Add to cart

14 Gasket ring 30x47x7 Available AP8125841

•

  Shaft Seal Piaggio Group · AP8125841 · Quantity needed: 2 Available

  € 2,04

  Add to cart

15 Bearing 25x47x12 Available AP8110094

•

  Wheel bearing 6005 2RS1, 25x47x12 mm Piaggio Group · AP8110094 · Quantity needed: 2 Available

  € 6,80

  Add to cart

16 Nipples L=34 Available 978810

•

  Spoke Nipples length: 34mm Piaggio Group · 978810 · Quantity needed: 36 Available

  € 14,13

  Add to cart

17 Snap ring Available 978811

•

  Snap-in Ring Piaggio Group · 978811 · Quantity needed: 36 Available

  € 2,76

  Add to cart

18 Screw Available AP8152043

•

  Screw M4x10 Piaggio Group · AP8152043 · Quantity needed: 2 Available

  € 2,18

  Add to cart

19 O-ring OR2025 Available GU90706061

•

  O-Ring Piaggio Group · GU90706061 · Quantity needed: 36 Available

  € 2,76

  Add to cart

20 Wheel rim 3.5x16" Backorder 2B0019544

•

  Rim 3.50x16, front Piaggio Group · 2B0019544 Backorder

  € 725,99

  Add to cart

21 Front spoke Backorder 2B001949

•

  Spoke Piaggio Group · 2B001949 · Quantity needed: 36 Backorder

  € 5,17

  Add to cart

22 Counterweight Backorder GU14616150

•

  Balance Weight Piaggio Group · GU14616150 Backorder

  € 20,06

  Add to cart

23 Front/rear tyre 2B001297 No longer available

• 2B001297 Front/rear tyre
  No longer available

24 Tubeless tyre valve Backorder GU03617710

•

  Tyre valves Piaggio Group · GU03617710 Backorder

  € 29,25

  Add to cart

25 Flanged TE screw M8x22 887762 No longer available

• 887762 Flanged TE screw M8x22 Quantity needed: 12
  No longer available

26 Cover 15 mm Available GU93180111

•

  Lid, Ø 15,00 mm Piaggio Group · GU93180111 Available

  € 3,17

  Add to cart

27 Front ABS sensor cable guide Available B044314

•

  Cable Guide Piaggio Group · B044314 Available

  € 7,72

  Add to cart

28 ABS front sensor Available 1D003747

•

  ABS sensor Piaggio Group · 1D003747 Available

  € 106,31

  Add to cart

29 Screw Available AP8152273

•

  Flanged Screw M5x15 Piaggio Group · AP8152273 Available

  € 2,18

  Add to cart
