Exploded view — Front Fork I

Products

1 Front fork Backorder 2B001427

•

  Fork Piaggio Group · 2B001427 Backorder

  € 845,64

  Add to cart

2 Tap.roller bearing Available GU92249225

•

  Steering head bearing Piaggio Group · GU92249225 · Quantity needed: 2 Available

  € 85,78

  Add to cart

3 Gasket ring Available AP8144146

•

  Oil seal Piaggio Group · AP8144146 Available

  € 14,91

  Add to cart

4 Washer Available AP8121307

•

  Shim Piaggio Group · AP8121307 Available

  € 28,73

  Add to cart

5 Side panel support rubber Available AP8144081

•

  Rubber Piaggio Group · AP8144081 Available

  € 4,34

  Add to cart

6 Rubber cup Available AP8220460

•

  Spacer Bush Piaggio Group · AP8220460 Available

  € 5,15

  Add to cart

7 Guard Backorder GU31497883

•

  Cover Piaggio Group · GU31497883 Backorder

  € 55,35

  Add to cart

8 Spacer Available GU31576183

•

  Sleeve Piaggio Group · GU31576183 · Quantity needed: 2 Available

  € 8,47

  Add to cart

9 Screw (M6x16 inox) Available GU98210616

•

  Flanged Screw M6x16, inox Piaggio Group · GU98210616 · Quantity needed: 2 Available

  € 4,21

  Add to cart
