Exploded view — Silencer

Products

1 Right exhaust manifold Right exhaust manifold No longer available

• Right exhaust manifold
  No longer available

2 Left exhaust manifold Left exhaust manifold No longer available

• Left exhaust manifold
  No longer available

3 Central manifold Central manifold No longer available

• Central manifold
  No longer available

4 RH silencer RH silencer No longer available

• RH silencer
  No longer available

5 LH silencer LH silencer No longer available

• LH silencer
  No longer available

6 Heat shield DX Heat shield DX No longer available

• Heat shield DX
  No longer available

7 Heat shield SX Heat shield SX No longer available

• Heat shield SX
  No longer available

8 Lamda sensor Available 1A024117

•

  Lambda Sensor Piaggio Group · 1A024117 · Quantity needed: 2 Available

  € 76,13

  Add to cart

9 Lamda sensor Available 1A024934

•

  Lamda sensor Piaggio Group · 1A024934 Available

  € 76,13

  Add to cart

10 RH support RH support No longer available

• RH support
  No longer available

11 LH support LH support No longer available

• LH support
  No longer available

12 RH hose clamp RH hose clamp No longer available

• RH hose clamp
  No longer available

13 LH hose clamp LH hose clamp No longer available

• LH hose clamp
  No longer available

14 RH hose clamp RH hose clamp No longer available

• RH hose clamp
  No longer available

15 LH hose clamp LH hose clamp No longer available

• LH hose clamp
  No longer available

16 Graphite bushing Graphite bushing No longer available

• Graphite bushing
  No longer available

17 Exhaust gasket Available 2B012220

•

  Exhaust Gasket Piaggio Group · 2B012220 · Quantity needed: 2 Available

  € 22,30

  Add to cart

18 Flanged nut M8 Available GU92660021

•

  Standard nut M8 Piaggio Group · GU92660021 · Quantity needed: 4 Available

  € 1,79

  Add to cart

19 Washer Available GU14615901

•

  Shim 8,4x13x0,8 mm Piaggio Group · GU14615901 · Quantity needed: 4 Available

  € 2,78

  Add to cart

20 Screw Available AP8150403

•

  Screw M6x45 Piaggio Group · AP8150403 · Quantity needed: 2 Available

  € 2,35

  Add to cart

21 Clip nuts (M6) Available 254485

•

  Sheet nut Piaggio Group · 254485 · Quantity needed: 6 Available

  € 2,04

  Add to cart

22 Screw (M6x10) Available 2B000215

•

  Screw Piaggio Group · 2B000215 · Quantity needed: 6 Available

  € 1,29

  Add to cart

23 Screw Available AP8152291

•

  Flanged Screw M8x45 Piaggio Group · AP8152291 · Quantity needed: 2 Available

  € 2,35

  Add to cart

24 Screw Available AP8152285

•

  Flanged Screw M8x16 Piaggio Group · AP8152285 · Quantity needed: 2 Available

  € 2,18

  Add to cart

25 Rubber spacer Available 2B007247

•

  Rubber Piaggio Group · 2B007247 · Quantity needed: 2 Available

  € 3,28

  Add to cart

26 T bush Available 2B011824

•

  T bush Piaggio Group · 2B011824 · Quantity needed: 4 Available

  € 2,80

  Add to cart

27 Spacer (rubber) Available 860171

•

  Rubber Piaggio Group · 860171 · Quantity needed: 4 Available

  € 5,00

  Add to cart

28 Clip nuts (M8) Available 575268

•

  Sheet nut Piaggio Group · 575268 · Quantity needed: 4 Available

  € 2,47

  Add to cart

29 Rubber exhaust Backorder AP8144071

•

  Buffer Piaggio Group · AP8144071 · Quantity needed: 4 Backorder

  € 14,31

  Add to cart

30 T bushing T bushing No longer available

• T bushing
  No longer available

31 Nut Available AP8152299

•

  Collar nut M6, self-locking Piaggio Group · AP8152299 · Quantity needed: 2 Available

  € 2,18

  Add to cart

32 Spacer Available B063174

•

  Spacer disc Piaggio Group · B063174 · Quantity needed: 2 Available

  € 18,20

  Add to cart

33 Washer Available AP8150016

•

  Washer Piaggio Group · AP8150016 · Quantity needed: 2 Available

  € 0,99

  Add to cart
