Exploded view — Engine Guard
‹ Back to model
Moto Guzzi V85 TT E4 ABS (NAFTA) 2020
Products
1 Right headstock cover Available
-
Cover, right Piaggio Group · 2B005529 Available · Shipped in 3–5 working days€ 14,53
2 Left headstock cover Available
-
Cover, left Piaggio Group · 2B005528 Available · Shipped in 3–5 working days€ 14,53
3 Screw Available
-
Thread Screw Piaggio Group · 258146 · Quantity needed: 11 Available · Shipped in 3–5 working days€ 0,99
4 Right injector covers Backorder
-
Cover, right Piaggio Group · 2B005808 Backorder · Shipped in 2–4 weeks€ 46,04
5 Left injector covers Backorder
-
Cover, left Piaggio Group · 2B005809 Backorder · Shipped in 2–4 weeks€ 46,04
6 Screw Available
-
Screw M5x9 Piaggio Group · AP8150500 · Quantity needed: 12 Available · Shipped in 3–5 working days€ 2,47
7 Rubber spacer Available
-
Plug Piaggio Group · AP8120001 Available · Shipped in 3–5 working days€ 6,27
8 Clip nuts (M5) Available
-
Sheet nut M5 Piaggio Group · AP8102375 · Quantity needed: 2 Available · Shipped in 3–5 working days€ 2,47
9 Cover support bracket Available
-
Bracket Piaggio Group · 2B002937 Available · Shipped in 3–5 working days€ 21,63
10 Starter motor cover Available
-
Starter Motor Cover Piaggio Group · 2B006168 Available · Shipped in 3–5 working days€ 25,00
11 LH sleeve protection Available
-
Fork guard, left Piaggio Group · 2B005763 Available · Shipped in 3–5 working days€ 51,79
-
Fork guard, with decals left, white Piaggio Group · 2H003216000Q4 Available · Shipped in 3–5 working days€ 134,33
-
Fork guard, with decals left, white Piaggio Group · 2H003326000Q4 Available · Shipped in 3–5 working days€ 134,33
12 RH sleeve protection Available
-
Fork guard, right Piaggio Group · 2B005699 Available · Shipped in 3–5 working days€ 51,79
-
Fork guard, with decals right, white Piaggio Group · 2H003215000Q4 Available · Shipped in 3–5 working days€ 134,33
-
Fork guard, with decals right, white Piaggio Group · 2H003325000Q4 Available · Shipped in 3–5 working days€ 134,33
13 Cable harness cover Available
-
Cover Piaggio Group · 2B006091 Available · Shipped in 3–5 working days€ 21,73
14 M5x12 pre-coated countersunk hex head Torx screw Available
-
Screw Piaggio Group · 2B003422 Available · Shipped in 3–5 working days€ 2,00
15 Connector box DX Available
-
Housing, right Piaggio Group · 2B005414 Available · Shipped in 3–5 working days€ 30,98
16 Connector box SX Available
-
Housing, left Piaggio Group · 2B005413 Available · Shipped in 3–5 working days€ 30,98
17 Screw with flange M5x12 Available
-
AP8152302 Screw with flange M5x12 Quantity needed: 2Screw Piaggio Group · 2B014101 ↻ Replaces AP8152302, which the manufacturer no longer supplies. Available · Shipped in 3–5 working days€ 3,78
18 Plastic rivet Available
-
Rivet plastic Piaggio Group · AP8102671 · Quantity needed: 2 Available · Shipped in 3–5 working days€ 0,99
19 Adhesive sponge 15X5 Backorder
-
Glue Sponge 15x5 mm Piaggio Group · AP8117003 Backorder · Shipped in 2–4 weeks€ 12,97
