Exploded view — Rear Headlamps - Turn Signal Lamps

Products

1 REAR LAMP Available 641440

•

  Rear light Piaggio Group · 641440 Available

  € 141,18

  Add to cart

2 Bulb (12V 3W) Available 294131

•

  Bulbs Bulb, 12 V, 3 W Piaggio Group · 294131 · Quantity needed: 2 Available

  € 2,88

  Add to cart

3 Bulb (12V 10W BAU15S) Available 584332

•

  Bulbs Bulb, 12 V, 10 W, orange Piaggio Group · 584332 · Quantity needed: 2 Available

  € 4,79

  Add to cart

4 Expansion plug Available 199190

•

  Expansion Anchor white, quadrangular Piaggio Group · 199190 · Quantity needed: 2 Available

  € 0,99

  Add to cart

5 Bulb (BA15S 12V 10W) Available 181746

•

  Bulbs Bulb, 12 V, 10 W, BA15s Piaggio Group · 181746 Available

  € 3,17

  Add to cart

6 Screw (M6x16) Available 575249

•

  Screw M6 Piaggio Group · 575249 · Quantity needed: 2 Available

  € 0,99

  Add to cart

7 Clip nuts (M6) Available 254485

•

  Sheet nut Piaggio Group · 254485 · Quantity needed: 2 Available

  € 2,04

  Add to cart

8 Lamp assy, number plate Available 58235R

•

  Number Plate Lights Piaggio Group · 58235R Available

  € 22,36

  Add to cart

9 Bulb (12V 5W T10) Available 2920225

•

  Bulbs Bulb, 12 V, 5 W, wedge base Piaggio Group · 2920225 Available

  € 3,42

  Add to cart

10 Screw Available 267115

•

  Sheet Metal Screw M4x16 Piaggio Group · 267115 Available

  € 0,99

  Add to cart

11 Washer Available 003054

•

  Washer Piaggio Group · 003054 Available

  € 1,77

  Add to cart

12 Lock-strap L=180mm Available 145298

•

  Cable Ties black, length: 18,0cm Piaggio Group · 145298 · Quantity needed: 3 Available

  € 1,43

  Add to cart
