Exploded view — Air Filter

‹ Back to model
Piaggio MP3 125 ie 2008-2011 (EMEA) 2008 Piaggio MP3 125 ie 2008-2011 (EMEA) 2008
Air Filter

Products

1 Air filter box Available 878926
2 Clamp Available 878927
  • Clamp Piaggio Group · 878927 Available
    € 14,54
3 Air bellow Available 874990
  • Intake Boot Piaggio Group · 874990 Available
    € 27,91
4 Air filter Available 8319970P
5 Gasket Available 844428
  • Gasket Piaggio Group · 844428 Available
    € 10,81
6 Screw Available 258146
  • Thread Screw Piaggio Group · 258146 · Quantity needed: 6 Available
    € 0,99
7 Screw Available 018640
  • Screw M6x50 Piaggio Group · 018640 · Quantity needed: 2 Available
    € 0,99
8 Washer Available 012533
  • Washer 6,6x11 mm Piaggio Group · 012533 · Quantity needed: 2 Available
    € 1,45
10 Spacer Available 830056
  • Sleeve Piaggio Group · 830056 · Quantity needed: 4 Available
    € 1,48
11 Clip nuts (M6) Available 254485
  • Sheet nut Piaggio Group · 254485 · Quantity needed: 2 Available
    € 2,04
12 Screw Available 479132
  • Adjustment Screw Piaggio Group · 479132 · Quantity needed: 2 Available
    € 12,78
13 Cap Available 827831
  • Cap, transparent Piaggio Group · 827831 · Quantity needed: 2 Available
    € 5,74
14 Clamp CM002920 No longer available
  • CM002920 Clamp Quantity needed: 2
    No longer available
15 Screw 259166 No longer available
  • 259166 Screw
    No longer available
17 Washer Available 003056
18 Bushing Available 830057
  • Spacer Bush Piaggio Group · 830057 · Quantity needed: 2 Available
    € 4,15
19 Nut Available 288245
  • Collar nut M6 Piaggio Group · 288245 Available
    € 0,99
20 Hose 844921 No longer available
  • 844921 Hose
    No longer available
