Exploded view — Secondary Air Box

Products

1 Flywheel cover sas Available 843567

•

  Lid, for secondary air filter Piaggio Group · 843567 Available

  € 119,26

  Add to cart

2 Cover sas Available 832971

•

  Lid Piaggio Group · 832971 Available

  € 22,88

  Add to cart

3 Air filter Available 832972

•

  Air Filter Insert Piaggio Group · 832972 Available

  € 3,74

  Add to cart

4 Gasket Available 832973

•

  Gasket Piaggio Group · 832973 Available

  € 44,43

  Add to cart

5 Diaphragm Available 82758R

•

  Reed valve for secondary air system Piaggio Group · 82758R Available

  € 30,08

  Add to cart

6 Screw Available 478533

•

  Thread Screw Piaggio Group · 478533 · Quantity needed: 3 Available

  € 1,26

  Add to cart

7 Screw Available 259151

•

  Screw M5x16 Piaggio Group · 259151 · Quantity needed: 4 Available

  € 1,25

  Add to cart

9 Intake pipe sas Backorder 843525

•

  Inlet pipe Piaggio Group · 843525 Backorder

  € 20,26

  Add to cart

10 Hose sas Available 833472

•

  Rubber bellows Piaggio Group · 833472 Available

  € 5,94

  Add to cart

11 Gasket Available 832059

•

  Gasket Piaggio Group · 832059 Available

  € 8,31

  Add to cart

12 Screw Available B016426

•

  Flanged Screw M6x14 Piaggio Group · B016426 · Quantity needed: 2 Available

  € 1,48

  Add to cart

13 Air pipe sas Available 833473

•

  Hose Piaggio Group · 833473 Available

  € 45,77

  Add to cart

14 Clamp Available CM001903

•

  Hose Clamp Piaggio Group · CM001903 Available

  € 2,18

  Add to cart

15 Clamp Available CM001905

•

  Hose Clamp Piaggio Group · CM001905 · Quantity needed: 2 Available

  € 1,82

  Add to cart

16 Clamp Available CM017807

•

  Clip Piaggio Group · CM017807 Available

  € 5,51

  Add to cart
