Exploded view — Reduction Unit

Products

1 Not available Available 8460265

•

  Gear Box Cover Piaggio Group · 8460265 Available

  € 121,17

  Add to cart

2 Wheel bearing Available 4789845

•

  Radial bearing 25x52x15 mm Piaggio Group · 4789845 Available

  € 28,86

  Add to cart

3 Bearing Available 83018R

•

  Radial bearing TM6302Y, 15x42x13 mm Piaggio Group · 83018R Available

  € 11,14

  Add to cart

4 Shoe fulcrum pin Available 272921

•

  Pin Piaggio Group · 272921 Available

  € 15,02

  Add to cart

5 10 - Seeger Available 006652

•

  Circlip Piaggio Group · 006652 Available

  € 1,80

  Add to cart

6 Oil seal Available 82899R

•

  Shaft Seal Piaggio Group · 82899R Available

  € 15,28

  Add to cart

7 Reduction unit cover gasket Available 847930

•

  Cover Gasket Piaggio Group · 847930 Available

  € 11,54

  Add to cart

8 5 - Screw Available B016805

•

  Flanged Screw M8x45 Piaggio Group · B016805 · Quantity needed: 7 Available

  € 1,48

  Add to cart

10 Driven pulley shaft 8738745 No longer available

• 8738745 Driven pulley shaft
  No longer available

11 Transmission shaft Backorder 8319145

•

  Primary reduction gear Piaggio Group · 8319145 Backorder

  € 302,97

  Add to cart

12 Rear wheel axis cpl. B0161805 No longer available

• B0161805 Rear wheel axis cpl.
  No longer available

13 Reducer breather pipe Available CM162202

•

  Breather Pipe Piaggio Group · CM162202 Available

  € 21,97

  Add to cart

14 Screw Available 269755

•

  Screw M8x12 Piaggio Group · 269755 Available

  € 1,59

  Add to cart

15 Washer Available 485703

•

  Washer 8,2x12x1 mm Piaggio Group · 485703 Available

  € 1,25

  Add to cart
