Exploded view — Carburettor, Assembly - Union Pipe

Products

1 Carburettor keihin CM153205 No longer available

• CM153205 Carburettor keihin
  No longer available
•

  Carburettor Keihin CVEK27-2707 Piaggio Group · CM156010 Backorder · Shipped in 2–4 weeks

  € 513,12

  Add to cart

2 Air bellow Available 829001

•

  Intake Manifold Piaggio Group · 829001 Available · Shipped in 3–5 working days

  € 30,31

  Add to cart

3 Clamp Available 1A000833

•

  Clamp Piaggio Group · 1A000833 Available · Shipped in 3–5 working days

  € 10,74

  Add to cart

4 Intake Manifold Available 871973

•

  Intake manifold Piaggio Group · 871973 Available · Shipped in 3–5 working days

  € 35,72

  Add to cart

5 Intake manifold Gasket Available 871167

•

  Gasket Piaggio Group · 871167 Available · Shipped in 3–5 working days

  € 1,73

  Add to cart

6 Screw (M6x22) Available 1A000352

• • Country: Taiwan


  Screw M6x22 Piaggio Group · 1A000352 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 3,71

  Add to cart

9 Resistor Module Available 82961R6

•

  Resistor Piaggio Group · 82961R6 Available · Shipped in 3–5 working days

  € 33,64

  Add to cart

11 Lock-strap L=180mm Available 145298

•

  Cable Ties black, length: 18,0cm Piaggio Group · 145298 Available · Shipped in 3–5 working days

  € 1,43

  Add to cart

12 Clamp Available CM002904

•

  Clamping Spring Piaggio Group · CM002904 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

13 Clamp Available CM002901

• • Carburettor version (C364M)
  • Injection version (C361M)
  • Year of manufacture: 2012
  • Year of manufacture: 2013
  • Country: Canada
  • Country: United States of America


  Clamping Spring Piaggio Group · CM002901 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart
