Exploded view — Front Body - Front Mudguard

‹ Back to model

Aprilia RSV 1000 2000

Products

1 Front mudguard AP8126682 No longer available

AP8126682 Front mudguard
- Colour: "R"acing Aprilia Black 2000
- Colour: "R"acing Diablo Black 2001-2002
- Colour: "R"acing Flashy Yellow 2001-2002
No longer available
AP8126843 Front mudguard, fl.yellow
- Colour: Flashy Yellow 2000
- Year of manufacture: 2000
- Country: United States of America
No longer available
AP8126842 Front mudguard, fl.yellow
- Colour: Flashy Yellow 2000
- Year of manufacture: 2000
No longer available
AP8126784 Front mudguard
- Colour: Aprilia Black 2000
- Year of manufacture: 2000
No longer available
AP8126838 Front mudguard, hot red
- Colour: Hot Red 2000
- Year of manufacture: 2000
No longer available
AP8126840 Front mudguard
- Colour: Electric Blue 2000
- Year of manufacture: 2000
No longer available
AP8126837 Front mudguard
- Colour: Aprilia Black 2000
- Year of manufacture: 2000
- Country: United States of America
No longer available
AP8126841 Front mudguard
- Colour: Electric Blue 2000
- Year of manufacture: 2000
- Country: United States of America
No longer available
AP8126854 Front mudguard
- Colour: "R"acing Aprilia Black 2000
- Colour: "R"acing Diablo Black 2001-2002
- Colour: "R"acing Flashy Yellow 2001-2002
- Country: United States of America
No longer available
AP8126839 Front mudguard, hot red
- Colour: Hot Red 2000
- Year of manufacture: 2000
- Country: United States of America
No longer available

2 Curved spring washer 5,3x10x0,5 Available AP8150272

- Colour: Special Edition
- Country: Switzerland
Snap Ring 5,3x10x0,5 mm Piaggio Group · AP8150272 · Quantity needed: 4 Available · Shipped in 3–5 working days

€ 4,09

3 Nut Available AP8150204

- Colour: Public Authorities China
- Colour: Special Edition
Standard nut M4 Piaggio Group · AP8150204 · Quantity needed: 4 Available · Shipped in 3–5 working days

€ 2,18

4 Screw Available 2B014101

Screw Piaggio Group · 2B014101 · Quantity needed: 4 Available · Shipped in 3–5 working days

€ 3,78
Flanged Screw M5x16 Piaggio Group · AP8152298 · Quantity needed: 4 Available · Shipped in 3–5 working days

€ 3,80

5 LH Front reflector support Backorder AP8148589

- ETV Capo Nord RALLY/RAID version
- ETV Capo Nord Standard version
- Country: Canada
- Country: United States of America
Bracket left, (USA) Piaggio Group · AP8148589 Backorder · Shipped in 2–4 weeks

€ 31,05

6 RH Front reflector support AP8148588 No longer available

AP8148588 RH Front reflector support
- ETV Capo Nord RALLY/RAID version
- ETV Capo Nord Standard version
- Country: Canada
- Country: United States of America
No longer available

7 Reflector, amber Available AP8124719

- Colour: Public Authorities China
- ETV Capo Nord RALLY/RAID version
- ETV Capo Nord Standard version
- Year of manufacture: 2001
- Year of manufacture: 2004
Reflector yellow Piaggio Group · AP8124719 · Quantity needed: 2 Available · Shipped in 3–5 working days

€ 17,01
