Exploded view — Exhaust Pipe

Products

1 Silencer protector (Chrome) Available AP8219452

•

  Heat Shield steel Piaggio Group · AP8219452 Available · Shipped in 3–5 working days

  € 47,64

  Add to cart

2 Washer (spring) Available AP8150376

• • Colour: Tuscany Tibet 2003
  • Year of manufacture: 2012
  • Year of manufacture: 2013
  • Country: Japan
  • Country: United States of America


  Shim 8,5x15x0,8 mm Piaggio Group · AP8150376 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,04

  Add to cart

3 Screw Available AP8152290

•

  Flanged Screw M8x40 Piaggio Group · AP8152290 Available · Shipped in 3–5 working days

  € 2,93

  Add to cart

4 Insulating washer Available AP8221297

•

  Washer Piaggio Group · AP8221297 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 1,73

  Add to cart

5 Screw Available AP8152246

• • Colour: Public Authorities China
  • Business
  • Business version


  Screw M6x16 Piaggio Group · AP8152246 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 4,37

  Add to cart

6 Hex socket screw Available AP8150521

•

  Screw Piaggio Group · AP8150521 Available · Shipped in 3–5 working days

  € 2,18

  Add to cart

7 Exhaust gasket Available AP8219212

•

  Exhaust Gasket Piaggio Group · AP8219212 Available · Shipped in 3–5 working days

  € 10,56

  Add to cart

  Alternatives from other brands



  GASKET EXHAUST Athena · S410485012010 Backorder · Shipped in 2–5 weeks

  € 3,96

  Add to cart

8 Screw Available AP8152291

•

  Flanged Screw M8x45 Piaggio Group · AP8152291 Available · Shipped in 3–5 working days

  € 2,35

  Add to cart

9 Silent block, exhaust pipe Backorder AP8220357

•

  Silentblock Piaggio Group · AP8220357 Backorder · Shipped in 2–4 weeks

  € 11,11

  Add to cart

10 Nut Available AP8150333

• • Year of manufacture: 1998
  • Year of manufacture: 2003
  • Country: United States of America


  Standard nut Piaggio Group · AP8150333 Available · Shipped in 3–5 working days

  € 1,48

  Add to cart

11 Spacer Available AP8121075

• • Year of manufacture: 1996
  • Year of manufacture: 2007


  Sleeve Piaggio Group · AP8121075 · Quantity needed: 2 Available · Shipped in 3–5 working days

  € 2,35

  Add to cart

12 Exhaust AP8219543 No longer available

• AP8219543 Exhaust
  • "DITECH" engine with direct fuel injection
  • Limited version 45 km/h
  • Spare part with EURO2 homologation
  No longer available
• AP8219593 Exhaust
  • Full power version
  • Limited version 45 km/h
  No longer available
