Exploded view — Drive Shaft

‹ Back to model

Derbi Dirt Boy - Dirt Kid 2004

Derbi Dirt Boy - Dirt Kid 2004

Drive Shaft

Products

1 Cylinder head gasket Available 969393

Cylinder Head Gasket Piaggio Group · 969393 Available

€ 7,20

2 Dowel pin Available B015956

Adapter Sleeve 9,5x15 Piaggio Group · B015956 Available

€ 1,32

3 PISTÓN 96923R No longer available

96923R PISTÓN
No longer available

4 Seeger Available 969213

Piston Clip Piaggio Group · 969213 Available

€ 0,99

5 Piston pin Available 969214

Piston Pin Piaggio Group · 969214 Available

€ 16,01

6 CYLINDER UNIT 834761 No longer available

834761 CYLINDER UNIT
No longer available

7 PACKING 840285 No longer available

840285 PACKING
No longer available
Cylinder Base Gasket Piaggio Group · 840284 Available

€ 4,11

8 Crankshaft 840132 No longer available

840132 Crankshaft
No longer available

9 Dowel pin Available 277916

Adapter Sleeve Piaggio Group · 277916 Available

€ 7,27
