Exploded view — Body
‹ Back to model
Derbi GPR 50 2T 2009
Products
1 Front mudguard Backorder
-
Mudguard without decals, front, black Piaggio Group · 86734200W4N Backorder€ 63,15
2 Screw (M6x100x10 INOX) Backorder
-
Screw M6, inox Piaggio Group · 866660 Backorder€ 2,64
3 Nut Available
-
Standard nut M6 Piaggio Group · 00000023060 Available€ 0,99
4 Screw (M6x30) Backorder
-
Screw M6x30 Piaggio Group · 862211 Backorder€ 2,64
5 Front mudguard support Available
-
Bracket for mudguard, front Piaggio Group · 867258 Available€ 14,65
6 Spacer Available
-
Sleeve Piaggio Group · AP8121032 Available€ 4,36
7 Bush Available
-
Sleeve Piaggio Group · 00H00700321 Available€ 5,15
8 Screw Available
-
Screw Piaggio Group · 00008062000 Available€ 2,54
9 Fuel tank cover, fluo red
-
86593300WR05 Fuel tank cover, fluo redNo longer available
-
86593300WG85 Fuel tank cover, greyNo longer available
-
Tank Cover, black Piaggio Group · 86593300WN45 Backorder€ 544,50
10 Screw Available
-
Screw Piaggio Group · 00000004510 Available€ 0,99
11 Washer Available
-
Shim Piaggio Group · 00H03800722 Available€ 1,75
12 Tank cover Backorder
-
Tank Cover, black Piaggio Group · 86593400W4N Backorder€ 30,71
13 Washer Available
-
Washer Piaggio Group · 861228 Available€ 2,69
14 Screw D3x10 TP88Z Available
-
Screw 3x10 mm Piaggio Group · 866499 Available€ 2,35
15 RH lower fairing, grey Backorder
-
Fairing, right Piaggio Group · R865927 Backorder€ 177,05
16 LH lower fairing, white Available
-
Fairing, left Piaggio Group · R865928 Available€ 180,97
18 Clip nuts (M5) Available
-
Sheet nut M5 Piaggio Group · 00G04401462 Available€ 1,48
19 Screw Available
-
Screw Piaggio Group · 2B014101 Available€ 3,78
21 Screw Available
-
Screw Piaggio Group · 847227 Available€ 6,70
22 Washer Available
-
Washer Piaggio Group · 00031105000 Available€ 1,72
24 RH side fairing Backorder
-
Fairing, right Piaggio Group · 86593000W4N Backorder€ 41,24
25 LH side fairing Backorder
-
Fairing, left Piaggio Group · 86592900W4N Backorder€ 41,24
26 Screw
-
00G01503701 ScrewNo longer available
27 Clip nuts (M6) Available
-
Sheet nut Piaggio Group · 254485 Available€ 2,04
30 Baffle
-
865945 BaffleNo longer available
31 Screw Available
-
Screw M6x20 Piaggio Group · AP8150044 Available€ 1,48
32 Washer Available
-
Shim Ø 6,00 mm Piaggio Group · 00402060001 Available€ 1,48
34 Screw Available
-
Allen screw M5 Piaggio Group · 00002051251 Available€ 2,78
37 Screw Available
-
Flanged Screw M5x9 Piaggio Group · AP8152339 Available€ 2,35
38 Clip nuts (M5) Available
-
Sheet nut M5 Piaggio Group · 00G04401462 Available€ 1,48
39 Fuel tank cover
-
866495 Fuel tank cover Quantity needed: 2No longer available
40 Fairlead Available
-
Clamp Piaggio Group · 864454 Available€ 2,63
41 Screw Available
-
Screw Piaggio Group · 00008051200 Available€ 1,60
42 Washer gasket Available
-
Shim Piaggio Group · 847226 Available€ 0,99
43 Nut Available
-
Standard nut Piaggio Group · 00000023050 Available€ 2,69
44 Washer Available
-
Shim Ø 6,00 mm Piaggio Group · 00D01200171 Available€ 1,48
45 Sticker kit
46 Reflector, amber Available
-
Reflector yellow Piaggio Group · AP8124719 Available€ 17,01
47 Nut Backorder
-
Standard nut Piaggio Group · 00000023040 Backorder€ 2,77
