Exploded view — Luggage Rack

Products

01 R-SCTO.CUAD.NG.C/C.VRNT 96 00F01968601 No longer available

• 00F01968601 R-SCTO.CUAD.NG.C/C.VRNT 96
  No longer available
• 00F01968603 R-SCTO.CUAD.C/C.REV.AZ.HIG.
  No longer available
• 00F01969602 R-SCTO.CUAD.NG.BAUX.VR 96 G.S.
  No longer available
• 00F01969601 R-SCTO.CUAD.NG.BAUX.VR 96 G.S.
  No longer available
• 00F01969604 R-SCTO.CUAD.AZ.HIGUER REV.GS01
  No longer available
• 00F01968602 R-SCTO.CUAD.NG.C/C.VR 96 G/NG.
  No longer available
• 00F01969603 R-SCTO.CUAD.GR.CROMO REV.GS00
  No longer available

02 Spacer (rubber) 00A01500352 No longer available

• 00A01500352 Spacer (rubber)
  No longer available

03 ADORNMENT, UPPER.BL.FR.FRAME 00F01510341 No longer available

• 00F01510341 ADORNMENT, UPPER.BL.FR.FRAME
  No longer available

04 DECAL 00F01507401 No longer available

• 00F01507401 DECAL
  No longer available
• 00F01507403 DECAL
  No longer available
• 00F05903231 DECAL.
  No longer available
• 00F01507402 DECAL
  No longer available
• 00F05903233 CALCA INF.IZ.CUAD.REV.GS 00
  No longer available

05 DECAL 00F01808963 No longer available

• 00F01808963 DECAL
  No longer available
• 00F05903223 CALCA INF.DR.CUAD.REV.GS 00
  No longer available
• 00F01808961 DECAL
  No longer available
• 00F05903221 DECAL.
  No longer available
• 00F01808962 DECAL
  No longer available

06 DECAL 00F01509781 No longer available

• 00F01509781 DECAL
  No longer available

07 PLACA CARACTERIST.START/99 AD 00F01823101 No longer available

• 00F01823101 PLACA CARACTERIST.START/99 AD
  No longer available
• 00F01815101 PLATE
  No longer available

08 Clip nuts (M6) Available 254485

•

  Sheet nut Piaggio Group · 254485 Available

  € 2,04

  Add to cart

09 ADORNMENT, UPPER.BL.FR.FRAME 00F04900761 No longer available

• 00F04900761 ADORNMENT, UPPER.BL.FR.FRAME
  No longer available

10 DECAL 00F01508402 No longer available

• 00F01508402 DECAL
  No longer available
• 00F01508401 DECAL
  No longer available
• 00F01508403 CALCA LAT.IZ.CHASIS REV 00 GS
  No longer available

11 ADORNMENT, UPPER.BL.FR.FRAME 00F04901761 No longer available

• 00F04901761 ADORNMENT, UPPER.BL.FR.FRAME
  No longer available

12 Self locking nut 10.m150 00000023100 No longer available

• 00000023100 Self locking nut 10.m150
  No longer available

13 Washer 00F02500981 No longer available

• 00F02500981 Washer
  No longer available

14 ENGINE FRONT FIXING AXLE 00F03002271 No longer available

• 00F03002271 ENGINE FRONT FIXING AXLE
  No longer available

15 CALCA LAT.DR.CHASIS REV 00 GS 00F01809963 No longer available

• 00F01809963 CALCA LAT.DR.CHASIS REV 00 GS
  No longer available
• 00F01809961 DECAL
  No longer available
• 00F01809962 DECAL
  No longer available

16 Washer Available 00000031060

•

  Washer Ø 6,00 mm Piaggio Group · 00000031060 Available

  € 0,99

  Add to cart

17 Screw Available 00012161600

•

  Screw M6 Piaggio Group · 00012161600 Available

  € 0,99

  Add to cart

18 SUPPORT 00F00601091 No longer available

• 00F00601091 SUPPORT
  No longer available

19 DECAL 00F01508731 No longer available

• 00F01508731 DECAL
  No longer available
• 00F01512731 DECAL
  No longer available

20 RUBBER GUIDE VARIANT 00F01503021 No longer available

• 00F01503021 RUBBER GUIDE VARIANT
  No longer available
• 00A01560021 PASACAB.LAT.DTROS.CHAS.VARIANT
  No longer available

21 RUBBER PETROL LEVEL 00F01800221 No longer available

• 00F01800221 RUBBER PETROL LEVEL
  No longer available

22 LEFT HAND PLATE SUB-ASSEMBLY 00F00102671 No longer available

• 00F00102671 LEFT HAND PLATE SUB-ASSEMBLY
  No longer available

23 RIGHT HAND PLATE SUB-ASSEMBLY 00F00102701 No longer available

• 00F00102701 RIGHT HAND PLATE SUB-ASSEMBLY
  No longer available

24 LEFT HAND PLATE SUB-ASSEMBLY Backorder 00F02201311

•

  Footrest left Piaggio Group · 00F02201311 Backorder

  € 27,77

  Add to cart

25 RIGHT HAND PLATE SUB-ASSEMBLY 00F02201301 No longer available

• 00F02201301 RIGHT HAND PLATE SUB-ASSEMBLY
  No longer available

26 FOOT REST PROTECTOR 00F01502101 No longer available

• 00F01502101 FOOT REST PROTECTOR
  No longer available

27 Spring 00F01500161 No longer available

• 00F01500161 Spring
  No longer available

28 Washer Available 00000031080

•

  Washer Ø 8,00 mm Piaggio Group · 00000031080 Available

  € 1,88

  Add to cart

29 Nut Backorder 00000023080

•

  Standard nut M8 Piaggio Group · 00000023080 Backorder

  € 1,44

  Add to cart

30 BUSHING 00F01500151 No longer available

• 00F01500151 BUSHING
  No longer available

31 Screw Available 00000004515

•

  Allen screw M5 Piaggio Group · 00000004515 Available

  € 1,44

  Add to cart

32 Screw Available 018509

•

  Screw M6x10 Piaggio Group · 018509 Available

  € 1,48

  Add to cart
