Exploded view — Rear Luggage Rack

Products

1 Passenger handle Available 1B007047000N13

•

  Luggage rack Piaggio Group · 1B007047000N13 Available

  € 240,38

  Add to cart
•

  Luggage rack Piaggio Group · 1B007047 Available

  € 193,39

  Add to cart

2 Screw Available 656894

•

  Torx screw Piaggio Group · 656894 · Quantity needed: 2 Available

  € 1,61

  Add to cart

3 Washer Available 012540

•

  Washer 14x8,3x1,8 mm Piaggio Group · 012540 · Quantity needed: 3 Available

  € 1,21

  Add to cart

4 Washer Available 003058

•

  Washer 15x8,4x1,5 mm Piaggio Group · 003058 · Quantity needed: 2 Available

  € 1,84

  Add to cart

5 Clip nuts (M8) Available 575268

•

  Sheet nut Piaggio Group · 575268 · Quantity needed: 2 Available

  € 2,47

  Add to cart

6 Screw w/ flange M8x60 Available 874747

•

  Flanged Screw M8x60 Piaggio Group · 874747 Available

  € 2,78

  Add to cart

7 Washer Available 709077

•

  Washer Piaggio Group · 709077 Available

  € 0,99

  Add to cart

8 Luggage rack upper cover Available 1B0070480000C

•

  Cover Piaggio Group · 1B0070480000C Available

  € 19,30

  Add to cart

9 Luggage carrier lower cover Available 1B0070490000C

•

  Cover Piaggio Group · 1B0070490000C Available

  € 48,40

  Add to cart

10 Screw (4.2 x 16) Available CM178601

•

  Sheet Metal Screw 4,2x16 mm Piaggio Group · CM178601 · Quantity needed: 8 Available

  € 1,45

  Add to cart

11 Clip nuts Available CM017410

•

  Sheet nut Piaggio Group · CM017410 · Quantity needed: 4 Available

  € 0,99

  Add to cart

12 Expansion plug Available 199190

•

  Expansion Anchor white, quadrangular Piaggio Group · 199190 · Quantity needed: 4 Available

  € 0,99

  Add to cart

13 Clip nuts Available D9004468091

•

  Clamp Piaggio Group · D9004468091 · Quantity needed: 3 Available

  € 5,15

  Add to cart
